Plan #126-141

Key Specs

  • 1760 sq ft

  • 3 Bedrooms

  • 2.5 Bathrooms

  • 2 Floors

  • 2 Garage

Plan Description

This villa-style narrow lot design is perfect for a waterfront location. Although only 20' wide, a double garage is included; yet the front facade and approach remain very attractive. Upon entering a spectacular two-storey foyer with curved staircase, one finds easy access to both the large living area and practical kitchen/utility area. Upstairs, the master suite entrance is flanked by ornamental columns which befit a room that boasts a large picture window, luxurious ensuite bath, and huge walk-in closet.
Modify This Plan

This plan can be customized!

Let us know your desired changes and get a free quote.
Click the button or call us now at 1-800-913-2350.

Floor Plans

Floor Plan - Main Floor Plan
Mediterranean Style House Plan - 3 Beds 2.5 Baths 1760 Sq/Ft Plan #126-141 Floor Plan - Main Floor Plan -
Floor Plan - Upper Floor Plan
Mediterranean Style House Plan - 3 Beds 2.5 Baths 1760 Sq/Ft Plan #126-141 Floor Plan - Upper Floor Plan -

Full Specs & Features

Basic Features

Baths : 2.5
Stories : 2
Garage Stalls : 2
Potential Bedrooms : 0
Bedrooms : 3


Depth : 62'
Width : 20'
Height : 24'


Garage Sq Ft : 371 sq ft
Main Floor Sq Ft : 852 sq ft
Basement Sq Ft : 822 sq ft
Total Sq Ft : 1760 sq ft *
Upper Floor Sq Ft : 902 sq ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Upper Ceiling Ft : 8'
Main Ceiling Ft : 8'


Roof Framing : Truss
Roof Load : 65 lbs psf
Primary Pitch : 6:12

Exterior Wall Framing

Exterior Wall Finish : Stucco
Insulation : Walls: R-22
Framing : 2"x6"

Bedroom Features

Walk In Closet
Upstairs Master Bedrooms

Kitchen Features

Peninsula Eating Bar

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Loft Balcony

Code Compliance

Irc 2006

Structural Information Provided

Structural Roof Framing
Structural 1st Floor Framing
Structural Calculations
Foundation Drawing
Structural Notes
Structural 2nd Floor Framing

What's included in this plan set

See a sample plan set

  • Floor Plans Including electrical
  • Foundation Plan
  • Cross Sections and other detail sections when required
  • Cabinet and Stair Details
  • Exterior Elevations - All four sides
  • Cover Page with artists rendering
  • Misc. Construction and Code Notes
*See important information before purchasing


Plan Options
5 Copy Set $625.00 5 printed plan sets mailed to you.
8 Copy Set $725.00 8 printed plan sets mailed to you.
Reproducible Set $775.00 For making minor changes to your house plans and inexpensive local printing. 1 printed set on Vellum or Bond paper.
CAD Set $1250.00 For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Single Set $550.00 One printed set for bidding purposes only. Not a legal building set.
Foundation Options
Basement $0.00 Ideal for level lot, lower level of home partially or fully underground.
Crawlspace $250.00 Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Daylight Basement $250.00 Ideal for sloping lot, lower level of home partially underground.
Slab $250.00 Ideal for level lot, single layer concrete poured directly on grade.
Additional Options
Additional Copies $50.00/each Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Mirror Reverse Sets $50.00/each Choose how many sets of the 5 or 8 copy set to mirror. Text and dimensions will be backwards. Click here for more information.
Right-Reading Reverse $150.00 Choose this option to reverse your plans and to have the text and dimensions readable. Click here for more information.
Material List $100.00 A list of building supplies needed to construct the infrastructure of your new house. Click here for more information.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

The Single Set and PDF Study Set are typically stamped "Not for Construction" and are to be used for studying / obtaining bids only. We do offer a 90% credit when you upgrade from a Single Set to a 5-Copy set (or greater).
