Plan #481-5

Key Specs


  • 2550 sq ft

  • 3 Bedrooms

  • 2 Bathrooms

  • 1 Floor

  • 1 Garage

Plan Description

This appealing 3 bedroom 2 bath 2,550 sq. ft. ranch house opens to a rear deck off the main living area, which is vaulted, with a glass gable for maximum daylight. The split layout puts the kitchen -- with walk-in pantry -- at the center between the master suite on one side and the two children's bedrooms on the other.

View more Ranch style house plans

Floor Plans

Main Floor Plan

Customize any features!

Our in-house design team can help you make all the modifications you have in mind in order to make this your dream home.

Get Free Quote

Full Specs & Features

Basic Features

Stories : 1
Garage Stalls : 1
Bedrooms : 3
Baths : 2

Dimension

Width : 61'
Height : 15'
Depth : 61'

Area

Decks Sq Ft : 500 sq ft
Porch Sq Ft : 300 sq ft
Total Sq Ft : 2550 sq ft
Main Floor Sq Ft : 2100 sq ft
Garage Sq Ft : 450 sq ft

Ceiling

Main Ceiling Ft : 8'
Garage Ceiling Ft : 9'
Upper Ceiling Ft : 12'

Roof

Roof Framing : truss

Exterior Wall Framing

Framing : masonry
Exterior Wall Finish : wood or stucco
Insulation : R-19

Kitchen Features

Kitchen Island
Walk In Pantry Cabinet Pantry

Additional Room Features

Main Floor Laundry
Master Sitting Area
Great Room Living Room

Garage Features

Front Entry Garage

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Covered Front Porch

More

Empty Nester

Energy Efficient Features

Energy Efficient Design

What's included in this plan set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

Pricing

Plan Set Price

5 Copy Set
$880.00
8 Copy Set
$980.00
Single Set
$630.00

Foundation Price

Slab
+$0.00

The Single Set and PDF Study Set are typically stamped "Not for Construction" and are to be used for studying / obtaining bids only. We do offer a 90% credit when you upgrade from a Single Set to a 5-Copy set (or greater).

Additional copies can be ordered at the time of purchase and within 90 days after your original purchase date.

Meet the Designer - Bud Dietrich AIA NCARB

null - Houseplans.com
“We should create right-sized homes that are gentle on us and our resources. Rather than getting distracted by questions of architectural style let’s use our own wisdom and common sense to create homes that are appropriate for their time and place.”

Bud Dietrich, AIA ALA NCARB
Harold Forrest Dietrich Architects LLC
Transforming Houses Into Homes™

Bud is a licensed architect with over 30 years' experience. His practice is in the single family residential arena and his projects have won local and national design awards and have been featured in books, magazines and newspapers as well as on HGTV. Bud is a member of the American Institute of Architects, serves on the Board of the Association of Licensed Architects and is a volunteer mentor to the Frank Lloyd Wright Preservation Trust. Bud looks to bridge traditional and modern aesthetics with designs that are rooted in the past while looking to the future.
