- FLOOR PLANS: Drawn at 1/4" = 1'-0" scale, and include room Lay-outs, door and window sizes, complete and accurate dimensions, locations of plant shelves and niches, Any specific notes, building section markers, floor Covering Locations
- BASEMENT PLAN (If applies): Drawn at 1/4" = 1'-0" scale, and includes Door and window sizes, Complete and accurate dimensions, any specific notes, building section markers, mechanical equipment location, electrical layouts
Finished and unfinished areas
- ELEVATION: Drawn at 1/4" = 1'-0" scale, and include exterior finishes, floor-to-floor heights, roof slope indicators, any specific notes, roof Overview
- ELECTRICAL PLANS: Drawn at 1/4" = 1'-0" scale, and include Switch and Outlet locations, lighting types & locations, T.V. and Phone locations
- FOUNDATION PLAN: Drawn at 1/4" = 1'-0" scale, and includes All posts and beam sizes and locations, door and window opening sizes, complete and accurate dimensions, all foundation wall and footing sizes, all code-related notes, building section markers, tags for different footing types
- BUILDING SECTIONS: Drawn at 1/4" = 1'-0" scale, and includes Beam sizes, connections, and locations, floor joist type and spacing, floor-to-floor heights, non-typical plate heights indicated
- TYPICAL WALL SECTIONS: Drawn at 1/4" = 1'-0" scale, and includes Section view through the home, ceiling details, niche/plant shelf details
Specific wall Elevations
- MISCELLANEOUS NOTES AND DETAILS: Miscellaneous framing details, stairway details, footing details, general notes covering all current code requirements for residential construction
Plan Set Price
Additional Construction Sets $50.00/each
Mirror Reverse Sets $0.00/each
Right-Reading Reverse $150.00
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas. Most of our plans show a basement and alternate crawl space or slab plan.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
