Plan 119-341

3073 sq/ft,
4 beds,
4 baths,
51' wide,
49' deep

Pricing

Plan Set
PDF Set
$1695.00
5 Copy Set
$2125.00
5 Copy and PDF Set
$2225.00
CAD and PDF Set
$2495.00
Foundation
Basement
+$0.00
Right-Reading Reverse
Each
+$200.00
Audio Video Design
Each
$165.00
Comprehensive Material List
Each
$495.00
Construction Guide
Each
$39.00
Lighting Design
Each
$165.00

House Features

Guest Suite
Main Floor Bedrooms
Split Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Family Room Keeping Room
Great Room Living Room
Loft
Storage Area
Oversized Garage
Side Entry Garage
Suited For View Lot
Balcony
Covered Rear Porch
Jack & Jill Bath

Styles Classifications

European
Mediterranean

Specifications

First Floor
1593 sq/ft height 9'
Second Floor
1480 sq/ft height 9'
Depth
49'
Height
28' 1"
Width
51'
Primary Pitch
4:12
Roof Framing
Combination Truss/Conventional
Roof Type
Shingle
Main Ceiling
9'
Upper Ceiling Ft
9'

Floor Plan - Lower Floor

European Floor Plan - Lower Floor Plan #119-341

Floor Plan - Main Floor

European Floor Plan - Main Floor Plan #119-341

Floor Plan - Upper Floor

European Floor Plan - Upper Floor Plan #119-341
