Plan #531-3

Houseplans.com European Photo Plan #531-3
  • 6700 sq ft
  • 5 beds
  • 8.50 baths
  • 49' wide
  • 105' deep

Pricing

Plan Set
5 Copy Set
$10000.00
CAD Set
$10000.00
PDF Set
$10000.00
Foundation
Slab
+$0.00
Additional Construction Sets
Each Additional Set
+$100.00

House Features

  • Guest Suite
  • Butler S Pantry
  • Nook Breakfast Area Dining
  • Walk In Pantry Cabinet Pantry
  • Kitchen Island
  • Parlor
  • Great Room Living Room
  • Library Room
  • Exercise Room
  • Bonus Play Flex Room
  • Den Office Study Computer
  • Upstairs Laundry
  • Rear Garage
  • Oversized Garage
  • Loft Balcony
  • Grill Deck Sundeck
  • Courtyard
  • Unusual Shape
  • Unique Features
  • Suited For Corner Lot
  • Suited For Narrow Lot
  • Parlor
  • Great Room Living Room
  • Library Room
  • Exercise Room
  • Bonus Play Flex Room
  • Den Office Study Computer
  • Upstairs Laundry
  • Teen Suite Jack Jill Bath

Styles Classifications

  • Mediterranean
  • European

Specifications

Bonus Sq Ft 950 sq ft
Garage Sq Ft 865 sq ft
Porch Sq Ft 1230 sq ft
Total Sq Ft 6700 sq ft
Lower Floor Sq Ft 2450 sq ft
Patios Sq Ft 700 sq ft
Upper Floor Sq Ft 3300 sq ft
Width 49'
Height 37'
Depth 105'
Primary Pitch 3:12
Roof Type Standing seam metal
Bonus Ceiling Ft 10'
Ceiling Details Groin-vaulted entry and coffered ceilings throughout
Upper Ceiling Ft 10'
Main Ceiling Ft 10'
Garage Ceiling Ft 11'
Main Floor Plan
Upper Floor Plan
Other Floor Plan

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see http://houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.

Note: All sales on house plans are final. No refunds or exchanges can be given once your order has been fulfilled or once we have begun to customize a home plan to your specifications.
