Plan #449-18

Mediterranean Exterior - Front Elevation Plan #449-18 - Houseplans.com
  • 4472 sq ft
  • 3 beds
  • 4 baths
  • 50' wide
  • 80' deep


Plan Set
5 Copy Set
Right-Reading Reverse

House Features

  • Main Floor Bedrooms
  • Split Bedrooms
  • Teen Suite Jack Jill Bath
  • Upstairs Bedrooms
  • Walk In Closet
  • Upstairs Master Bedrooms
  • Kitchen Island
  • Butler's Pantry
  • Breakfast Nook
  • Peninsula Eating Bar
  • Walk In Pantry Cabinet Pantry
  • Family Room Keeping Room
  • Master Sitting Area
  • Upstairs Laundry
  • Mud Room
  • Hobby Rec Room Game Room
  • Den Office Study Computer
  • Wine Cellar
  • Front Entry Garage
  • Loft Balcony
  • Covered Rear Porch
  • Courtyard
  • Outdoor Kitchen Grill
  • Unusual Shape
  • Suited For Vacation Home
  • Suited For View Lot
  • Suited For Narrow Lot
  • Suited For Corner Lot
  • Family Room Keeping Room
  • Master Sitting Area
  • Upstairs Laundry
  • Mud Room
  • Hobby Rec Room Game Room
  • Den Office Study Computer
  • Wine Cellar

Styles Classifications

  • Mediterranean
  • European


Total Sq Ft 4472 sq ft
Upper Floor Sq Ft 2170 sq ft
Main Floor Sq Ft 2302 sq ft
Width 50'
Height 31'
Depth 80'
Primary Pitch 6:12
Roof Type Tile
Roof Framing Conventional
Garage Ceiling Ft 11'
Ceiling Details Vaulted ceiling in family room and master bedroom, groin vault in living room, coffered ceiling in dining
Upper Ceiling Ft 10'
Main Ceiling Ft 11'
Floor Plan - Main Floor Plan
Floor Plan - Upper Floor Plan

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see http://houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
