Plan 484-8

Plan 484-8
6860 sq/ft,
4 beds,
5 baths,
100' wide,
100' deep

Pricing

Plan Set
PDF Set
$5995.00
5 Copy Set
$6500.00
8 Copy Set
$6800.00
CAD Set
$9995.00
Study Set
$995.00
Single Set
$9995.00
Foundation
Slab
+$0.00
Crawlspace
+$200.00
Right-Reading Reverse
Each
+$200.00
Additional Construction Sets
Each Additional Set
+$55.00/each
Audio Video Design
Each
$100.00
Construction Guide
Each
$39.00
Lighting Design
Each
$200.00
Mirror Reversed Sets
Each Additional Set
+$200.00

House Features

Guest Suite
Main Floor Bedrooms
Split Bedrooms
Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Breakfast Nook
Butler's Pantry
Kitchen Island
Walk In Pantry Cabinet Pantry
Den Office Study Computer
Family Room Keeping Room
Great Room Living Room
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Master Sitting Area
Play Flex Room
Wine Cellar
Oversized Garage
Side Entry Garage
Suited For Corner Lot
Suited For View Lot
Balcony
Breezeway
Courtyard
Covered Front Porch
Covered Rear Porch
Suited For Vacation Home

Styles Classifications

Mediterranean
European

Specifications

Garage
855 sq/ft
Main Floor
4180 sq/ft
Patios
2407 sq/ft
Porch
280 sq/ft
Upper Floor
2680 sq/ft
Depth
100'
Height
29'
Width
100'
Primary Pitch
3.5/12
Roof Framing
truss
Roof Load
50
Roof Type
wood
Bonus Ceiling
13'
Ceiling Details
Beautiful open beam ceilings. Coved and crown ceilings. Cathedral Ceilings in the Master Suite, Formal Dining, and detached Guest house.
Garage Ceiling
10'
Lower Ceiling
11'
Main Ceiling
11'
Upper Ceiling Ft
22'

Floor Plan - Main Floor

Mediterranean Floor Plan - Main Floor Plan #484-8

Floor Plan - Upper Floor

Mediterranean Floor Plan - Upper Floor Plan #484-8
Houseplans.com
Questions about this plan? Visit Houseplans.com today or call 1-800-913-2350

View this plan at https://www.houseplans.com/plan/8700-square-feet-4-bedroom-5-bathroom-3-garage-mediterranean-european-40590

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see https://www.houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
