Plan 930-442

Plan 930-442
6079 sq/ft,
5 beds,
6 baths,
88' wide,
112' 1" deep

Pricing

Plan Set
PDF Set
$4863.00
CAD Set
$9119.00
Foundation
Stem Wall Foundation
+$0.00
Framing
Wood 2x6
$0.00
Right-Reading Reverse
Each
+$375.00
Additional Construction Sets
Each Additional Set
+$65.00/each
Audio Video Design
Each
$165.00
Construction Guide
Each
$39.00
Material List
Each
+$195.00

House Features

Fireplace
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Master Sitting Area
Media Room
Open Floor Plan
Storage Area
Sunroom
Vaulted / Cathedral Ceilings
Balcony
Courtyard
Covered Rear Porch
Deck
Screened Porch

Styles Classifications

Mediterranean
Southwest

Specifications

Deck
633 sq/ft
First Floor
4429 sq/ft
Garage
778 sq/ft
Second Floor
1650 sq/ft
Depth
112' 1"
Height
35' 2"
Width
88'
Primary Pitch
7:12
Roof Type
Concrete

Floor Plan - Main Floor

Mediterranean Floor Plan - Main Floor Plan #930-442

Floor Plan - Upper Floor

Mediterranean Floor Plan - Upper Floor Plan #930-442
Houseplans.com
Questions about this plan? Visit Houseplans.com today or call 1-800-913-2350

View this plan at https://www.houseplans.com/plan/6079-square-feet-5-bedroom-6-00-bathroom-3-garage-mediterranean-sp154838

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see https://www.houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
