Plan 942-37

Plan 942-37
4520 sq/ft,
4 beds,
4.5 baths,
136' 8" wide,
70' 8" deep

Pricing

Plan Set
PDF Set
$4150.00
CAD and PDF Set
$4375.00
Study Set
$1725.00
Foundation
Basement
+$0.00
Daylight Basement
+$0.00
Slab
+$0.00
Framing
Wood 2x6
$0.00
Right-Reading Reverse
Each
+$800.00
Audio Video Design
Each
$165.00
Construction Guide
Each
$39.00
Lighting Design
Each
$165.00

House Features

Fireplace
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Den Office Study Computer
Great Room Living Room
Loft
Main Floor Laundry
Master Sitting Area
Mud Room
Open Floor Plan
Storage Area
Sunroom
Upstairs Laundry
Vaulted / Cathedral Ceilings
Side Entry Garage
Balcony
Covered Front Porch
Covered Rear Porch
Outdoor Fireplace
Screened Porch
Wrap Around Porch

Styles Classifications

Prairie
Craftsman

Specifications

Basement Unfinished
2787 sq/ft
Deck
559 sq/ft
First Floor
2826 sq/ft height 10'
Garage
1485 sq/ft
Second Floor
1694 sq/ft height 9'
Storage
78 sq/ft
Depth
70' 8"
Height
30' 2"
Width
136' 8"
Primary Pitch
5:12
Roof Framing
Truss
Roof Type
Composition
Secondary Pitch
3:12

Floor Plan - Main Floor

Prairie Floor Plan - Main Floor Plan #942-37

Floor Plan - Upper Floor

Prairie Floor Plan - Upper Floor Plan #942-37

Floor Plan - Lower Floor

Prairie Floor Plan - Lower Floor Plan #942-37
Houseplans.com
Questions about this plan? Visit Houseplans.com today or call 1-800-913-2350

View this plan at https://www.houseplans.com/plan/4520-square-feet-4-bedroom-4-50-bathroom-4-garage-prairie-craftsman-sp154582

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see https://www.houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.

Note: All sales on house plans are final. No refunds or exchanges can be given once your order has been fulfilled or once we have begun to customize a home plan to your specifications.
