Plan 930-475

Plan 930-475
6136 sq/ft,
5 beds,
5.5 baths,
89' 8" wide,
130' 4" deep

Pricing

Plan Set
PDF Set
$4909.00
CAD Set
$9204.00
Foundation
Stem Wall Foundation
+$0.00
Basement
+$375.00
Framing
Block
$0.00
Insulated Concrete Forms
$575.00
Wood 2x6
$575.00
Additional Construction Sets
Each Additional Set
+$65.00/each
Audio Video Design
Each
$165.00
Construction Guide
Each
$39.00
Material List
Each
+$195.00

House Features

Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Den Office Study Computer
Great Room Living Room
Hobby Rec Room Game Room
Loft
Master Sitting Area
Mud Room
Storage Area
Wet Bar
Front Entry Garage
Balcony
Courtyard
Covered Front Porch
Covered Rear Porch
Outdoor Kitchen Grill

Styles Classifications

Contemporary
Modern
Mediterranean

Specifications

First Floor
5127 sq/ft
Garage
1338 sq/ft
Porch
1942 sq/ft
Second Floor
1009 sq/ft
Depth
130' 4"
Height
33' 2"
Width
89' 8"
Primary Pitch
12/6
Roof Framing
Truss
Roof Type
Metal
Ceiling Details
Decorative ceiling details throughout the plan.

Floor Plan - Main Floor

Contemporary Floor Plan - Main Floor Plan #930-475

Floor Plan - Upper Floor

Contemporary Floor Plan - Upper Floor Plan #930-475
Houseplans.com
Questions about this plan? Visit Houseplans.com today or call 1-800-913-2350

View this plan at https://www.houseplans.com/plan/6136-square-feet-5-bedroom-5-1-bathroom-4-garage-contemporary-european-mediterranean-sp94277

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see https://www.houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
