Plan #21-309

Craftsman Exterior - Front Elevation Plan #21-309 - Houseplans.com
  • 2199 sq ft
  • 4 beds
  • 2.5 baths
  • 71' wide
  • 62' deep


Material List
Mirror Reversed Sets
Each Additional Set
Plan Set
5 Copy Set
Reproducible Set
Single Set
Right-Reading Reverse
Additional Construction Sets
Each Additional Set

House Features

  • Split Bedrooms
  • Walk In Closet
  • Breakfast Nook
  • Walk In Pantry Cabinet Pantry
  • Peninsula Eating Bar
  • Storage Area
  • Bonus Play Flex Room
  • Great Room Living Room
  • Den Office Study Computer
  • Side Entry Garage
  • Covered Front Porch
  • Covered Rear Porch
  • Suited For Corner Lot
  • Storage Area
  • Bonus Play Flex Room
  • Great Room Living Room
  • Den Office Study Computer

Styles Classifications

  • Traditional
  • Craftsman


Main Floor Sq Ft 2199 sq ft
Porch Sq Ft 425 sq ft
Garage Sq Ft 823 sq ft
Total Sq Ft 2199 sq ft
Bonus Sq Ft 436 sq ft
Width 71'
Height 25'
Depth 62'
Primary Pitch 8:12
Roof Type Hip / Gable
Secondary Pitch 12:12
Roof Load 30 lbs psf
Roof Framing stick
Main Ceiling Ft 9'
Bonus Ceiling Ft 8'
Floor Plan - Main Floor Plan
Floor Plan - Upper Floor Plan

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see http://houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.

Note: All sales on house plans are final. No refunds or exchanges can be given once your order has been fulfilled or once we have begun to customize a home plan to your specifications.
