Plan #449-7

Modern Exterior - Front Elevation Plan #449-7 - Houseplans.com
  • 3611 sq ft
  • 3 beds
  • 4 baths
  • 34' wide
  • 91' deep


Plan Set

House Features

  • Guest Suite
  • Walk In Closet
  • Main Floor Bedrooms
  • Split Bedrooms
  • Main Floor Master Bedroom
  • Upstairs Bedrooms
  • Kitchenette Wet Bar
  • Peninsula Eating Bar
  • Walk In Pantry Cabinet Pantry
  • Great Room Living Room
  • Upstairs Laundry
  • Wet Bar
  • Hobby Rec Room Game Room
  • Front Entry Garage
  • Loft Balcony
  • Courtyard
  • Unusual Shape
  • Suited For Vacation Home
  • Suited For Narrow Lot
  • Great Room Living Room
  • Upstairs Laundry
  • Wet Bar
  • Hobby Rec Room Game Room

Styles Classifications

  • Modern


Main Floor Sq Ft 1962 sq ft
Total Sq Ft 3611 sq ft
Upper Floor Sq Ft 1649 sq ft
Garage Sq Ft 394 sq ft
Width 34'
Depth 91'
Height 31'
Roof Type Asphalt shingle / Metal
Primary Pitch 5:12
Secondary Pitch 4:12
Garage Ceiling Ft 10'
Upper Ceiling Ft 9'
Main Ceiling Ft 10'
Ceiling Details Two-story Family Room
Floor Plan - Main Floor Plan
Floor Plan - Upper Floor Plan

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see http://houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
