Plan 120-172

2847 sq/ft,
3 beds,
3 baths,
88' 8" wide,
84' 10" deep

Pricing

Plan Set
5 Copy Set
$1345.00
8 Copy Set
$1645.00
PDF Set
$1845.00
CAD Set
$2995.00
Study Set
$945.00
Foundation
Slab
+$0.00
Crawlspace
+$300.00
Basement
+$400.00
Daylight Basement
+$400.00
Right-Reading Reverse
Each
+$300.00
Additional Construction Sets
Each Additional Set
+$100.00/each
Audio Video Design
Each
$100.00
Construction Guide
Each
$39.00
Home Furniture Planner
Each
$19.00
Lighting Design
Each
$100.00

House Features

Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Main Floor Laundry
Media Room
Mud Room
Play Flex Room
Unfinished Future Space
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Main Floor Laundry
Media Room
Mud Room
Play Flex Room
Unfinished Future Space
Side Entry Garage
Suited For Corner Lot
Suited For Sloping Lot
Suited For View Lot
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Outdoor Kitchen Grill
Empty Nester
Jack & Jill Bath
Suited For Vacation Home
Unusual Shape
Wheelchair Adaptable

Styles Classifications

Craftsman House Plans and Home Plan Designs

Specifications

Basement Unfinished
2847 sq/ft
Bonus
934 sq/ft height 9'
First Floor
2847 sq/ft
Garage
896 sq/ft
Depth
84' 10"
Height
34' 10"
Width
88' 8"
Primary Pitch
12:12
Roof Framing
stick
Roof Load
20
Roof Type
gable
Secondary Pitch
4:12
Bonus Ceiling
9'
Ceiling Details
Stepped ceiling in Dining and Family Vaulted in Master
Garage Ceiling
9'
Main Ceiling
10'

Floor Plan - Main Floor Plan

Lodge craftsman house by David Wiggins - 2900 sft with great indoor and outdoor living Houseplans #120-172

Floor Plan - Upper Floor Plan

Craftsman Floor Plan - Upper Floor Plan Plan #120-172
