Plan 909-1

2777 sq/ft,
3 beds,
2.5 baths,
46' 2" wide,
82' 5" deep

Pricing

Plan Set
PDF Set
$2400.00
Reproducible Set
$2600.00
5 Copy Set
$2800.00
8 Copy Set
$2900.00
CAD Set
$3800.00
Study Set
$1800.00
Single Set
$2000.00
Foundation
Basement
+$0.00
Daylight Basement
+$200.00
Slab
+$200.00
Additional Construction Sets
Each Additional Set
+$50.00/each
Audio Video Design
Each
$100.00
Construction Guide
Each
$39.00
Lighting Design
Each
$100.00

House Features

Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Eating Bar
Kitchen Island
Den Office Study Computer
Great Room Living Room
Loft
Master Sitting Area
Mud Room
Upstairs Laundry
Wine Cellar
Den Office Study Computer
Great Room Living Room
Loft
Master Sitting Area
Mud Room
Upstairs Laundry
Wine Cellar
Oversized Garage
Side Entry Garage
Friend S Entry
Suited For Corner Lot
Suited For Narrow Lot
Suited For Sloping Lot
Suited For View Lot
Balcony
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Jack & Jill Bath
Unusual Shape

Styles Classifications

Modern

Specifications

Basement
1290 sq/ft
Decks
276 sq/ft
Garage
960 sq/ft
Main Floor
1290 sq/ft
Porch
88 sq/ft
Upper Floor
1487 sq/ft
Depth
82' 5"
Height
28' 6"
Width
46' 2"
Primary Pitch
3:12
Roof Framing
roof trusses
Roof Load
varies by location
Roof Type
shed
Secondary Pitch
.25:12
Garage Ceiling
10' 4"
Lower Ceiling
9'
Main Ceiling
9'
Upper Ceiling Ft
13'

Floor Plan - Main Floor

Modern style House plan, main level floor plan

Floor Plan - Other Floor

Modern Floor Plan - Other Floor Plan #909-1

Floor Plan - Upper Floor

Modern Floor Plan - Upper Floor Plan #909-1
Houseplans.com
Questions about this plan? Visit Houseplans.com today or call 1-800-913-2350

View this plan at https://www.houseplans.com/plan/2777-square-feet-3-bedroom-2-5-bathroom-3-garage-modern-38869

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see https://www.houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.

Note: All sales on house plans are final. No refunds or exchanges can be given once your order has been fulfilled or once we have begun to customize a home plan to your specifications.
