Plan 930-276

3474 sq/ft,
4 beds,
4.5 baths,
80' wide,
63' 8" deep

Pricing

Plan Set
PDF Set
$1841.00
Reproducible Set
$1841.00
CAD Set
$3121.00
Foundation
Stem Wall Foundation
+$0.00
Basement
+$275.00
Framing
Wood 2x6
$0.00
Additional Construction Sets
Each Additional Set
+$65.00/each
Audio Video Design
Each
$100.00
Construction Guide
Each
$39.00
Home Furniture Planner
Each
$19.00
Lighting Design
Each
$200.00
Material List
Each
+$150.00
Right-Reading Reverse
Each
+$275.00

House Features

Fireplace
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Main Floor Master Bedroom
Split Bedrooms
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Den Office Study Computer
Great Room Living Room
Loft
Main Floor Laundry
Master Sitting Area
Open Floor Plan
Storage Area
Sunroom
Den Office Study Computer
Great Room Living Room
Loft
Main Floor Laundry
Master Sitting Area
Open Floor Plan
Storage Area
Sunroom
Side Entry Garage
Balcony
Courtyard
Covered Front Porch
Covered Rear Porch
Deck
Outdoor Fireplace
Screened Porch

Styles Classifications

Mediterranean House Plans
European House Plans
Traditional House Plans

Specifications

Deck
304 sq/ft
First Floor
2226 sq/ft
Garage
564 sq/ft
Patio
571 sq/ft
Second Floor
1248 sq/ft
Depth
63' 8"
Height
30'
Width
80'
Primary Pitch
6:12
Roof Framing
Combination Truss/Conventional
Roof Type
Tile

Floor Plan - Main Floor Plan

Mediterranean Floor Plan - Main Floor Plan Plan #930-276

Floor Plan - Upper Floor Plan

Mediterranean Floor Plan - Upper Floor Plan Plan #930-276
Logo
Questions about this plan? Visit Houseplans.com today or call 1-800-913-2350

You can view this plan at https://www.houseplans.com/plan/3474-square-feet-4-bedroom-4-50-bathroom-2-garage-mediterranean-sp216774

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see https://www.houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
