Plan 928-234

3203 sq/ft,
4 beds,
2.5 baths,
54' wide,
58' deep

Pricing

Plan Set
PDF Set
$995.00
CAD Set
$2995.00
Foundation
Daylight Basement
+$0.00
Framing
Wood 2x6
$0.00
Right-Reading Reverse
Each
+$195.00
Audio Video Design
Each
$100.00
Comprehensive Material List
Each
$495.00
Construction Guide
Each
$39.00
Lighting Design
Each
$200.00

House Features

Fireplace
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Split Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Den Office Study Computer
Exercise Room
Family Room Keeping Room
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Master Sitting Area
Media Room
Mud Room
Open Floor Plan
Sunroom
Unfinished Future Space
Vaulted / Cathedral Ceilings
Side Entry Garage
Covered Front Porch
Deck
Screened Porch

Styles Classifications

Tudor
European

Specifications

Basement Unfinished
1151 sq/ft height 9'
First Floor
1564 sq/ft height 10'
Second Floor
1639 sq/ft height 8'
Depth
58'
Height
35'
Width
54'
Primary Pitch
12:12
Roof Framing
Truss
Roof Type
Asphalt

Floor Plan - Other Floor

Tudor Floor Plan - Other Floor Plan #928-234

Floor Plan - Lower Floor

Tudor Floor Plan - Lower Floor Plan #928-234

Floor Plan - Main Floor

Tudor Floor Plan - Main Floor Plan #928-234

Floor Plan - Upper Floor

Tudor Floor Plan - Upper Floor Plan #928-234
Houseplans.com
Questions about this plan? Visit Houseplans.com today or call 1-800-913-2350

View this plan at https://www.houseplans.com/plan/3203-square-feet-4-bedroom-2-50-bathroom-3-garage-tudor-european-sp219044

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see https://www.houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
