Plan #20-2315

  • 2232 sq/ft 4 Bedrooms 3 Baths 2 Stories 2 Garages

Pricing

Plan Set
PDF Set
$1005.00
Reproducible Set
$1005.00
5 Copy Set
$1080.00
8 Copy Set
$1200.00
CAD Set
$1759.00
Single Set
$653.00
Foundation
Basement
+$0.00
Crawlspace
+$195.00
Slab
+$195.00
Additional Construction Sets
+$45.00/each
Audio Video Design
+$100.00
Construction Guide
+$39.00
Home Furniture Planner
+$19.00
Lighting Design
+$100.00
Mirror Reversed Sets
+$45.00
Right-Reading Reverse
+$195.00

House Features

  • Main Floor Bedrooms
  • Main Floor Master Bedroom
  • Split Bedrooms
  • Upstairs Bedrooms
  • Walk In Closet
  • Eating Bar
  • Kitchen Island
  • Walk In Pantry Cabinet Pantry
  • Den Office Study Computer
  • Great Room Living Room
  • Main Floor Laundry
  • Mud Room
  • Den Office Study Computer
  • Great Room Living Room
  • Main Floor Laundry
  • Mud Room
  • Front Entry Garage
  • Suited For Narrow Lot
  • Covered Front Porch
  • Economical To Build
  • Empty Nester

Styles Classifications

  • Cottage House Plans
  • Craftsman House Plans and Home Plan Designs
  • Country House Plans

Specifications

Garage 512 sq/ft
Main Floor 1676 sq/ft
Porch 1128 sq/ft
Upper Floor 556 sq/ft
Depth 54'
Height 26' 9"
Width 44'
Primary Pitch 7:12
Roof Framing Conventional
Roof Type Asphalt Shingle
Secondary Pitch 7:12
Ceiling Details Sloped ceiling in Great Room; Kitchen and Dining Room; 9' to 10' step ceiling in Master Suite
Main Ceiling 9'
Upper Ceiling Ft 8'
Cottage Floor Plan - Main Floor Plan Plan #20-2315
Cottage Floor Plan - Upper Floor Plan Plan #20-2315

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see http://houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
