Plan 930-505

5045 sq/ft,
4 beds,
4.5 baths,
52' wide,
66' 4" deep

Pricing

Plan Set
PDF Set
$4036.00
CAD Set
$7568.00
Foundation
Island Basement
+$0.00
Framing
Block
$0.00
Additional Construction Sets
Each Additional Set
+$65.00/each
Audio Video Design
Each
$100.00
Construction Guide
Each
$39.00

House Features

Split Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Breakfast Nook
Butler's Pantry
Kitchen Island
Great Room Living Room
Main Floor Laundry
Storage Area
Great Room Living Room
Main Floor Laundry
Storage Area
Side Entry Garage
Covered Front Porch
Covered Rear Porch
Elevator

Styles Classifications

European
Mediterranean

Specifications

Basement
789 sq/ft
Decks
195 sq/ft
Garage
1384 sq/ft
Lower Floor
121 sq/ft
Main Floor
2592 sq/ft
Porch
1353 sq/ft
Upper Floor
2332 sq/ft
Depth
66' 4"
Height
39'
Width
52'
Primary Pitch
4/12
Roof Framing
Truss/Stick
Roof Type
Concrete
Ceiling Details
Upper Floor: Variable Lower Floor: 9'6"
Main Ceiling
10'

Floor Plan - Main Floor

European Floor Plan - Main Floor Plan #930-505

Floor Plan - Lower Floor

European Floor Plan - Lower Floor Plan #930-505

Floor Plan - Upper Floor

European Floor Plan - Upper Floor Plan #930-505
Houseplans.com
Questions about this plan? Visit Houseplans.com today or call 1-800-913-2350

View this plan at https://www.houseplans.com/plan/5045-square-feet-4-bedroom-4-5-bathroom-3-garage-european-mediterranean-sp258492

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see https://www.houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.

Note: All sales on house plans are final. No refunds or exchanges can be given once your order has been fulfilled or once we have begun to customize a home plan to your specifications.
