Plan 46-893

1883 sq/ft,
3 beds,
2.5 baths,
41' 5" wide,
46' 8" deep

Pricing

Plan Set
PDF Set
$895.00
Reproducible Set
$895.00
5 Copy and PDF Set
$950.00
8 Copy Set
$950.00
Eight Copy and PDF Set
$995.00
CAD Set
$1350.00
Study Set
$695.00
Foundation
Basement
+$0.00
Framing
Wood 2x4
$0.00
Right-Reading Reverse
Each
+$150.00
Audio Video Design
Each
$100.00
Construction Guide
Each
$39.00

House Features

Split Bedrooms
Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Kitchen Island
Great Room Living Room
Mud Room
Upstairs Laundry
Suited For Narrow Lot
Covered Front Porch
Economical To Build

Styles Classifications

Contemporary
Prairie

Specifications

Basement
972 sq/ft
Garage
463 sq/ft
Main Floor
972 sq/ft
Porch
70 sq/ft
Upper Floor
911 sq/ft
Depth
46' 8"
Height
23' 6"
Width
41' 5"
Primary Pitch
4/12
Roof Framing
Truss
Roof Load
47 psf
Roof Type
Shingle
Secondary Pitch
4/12
Garage Ceiling
10' 6"
Lower Ceiling
7' 10"
Main Ceiling
8' 1"
Upper Ceiling Ft
8' 1"

Floor Plan - Main Floor

Contemporary Floor Plan - Main Floor Plan #46-893

Floor Plan - Upper Floor

Contemporary Floor Plan - Upper Floor Plan #46-893

Floor Plan - Lower Floor

Contemporary Floor Plan - Lower Floor Plan #46-893
Houseplans.com
Questions about this plan? Visit Houseplans.com today or call 1-800-913-2350

View this plan at https://www.houseplans.com/plan/1883-square-feet-3-bedroom-2-5-bathroom-2-garage-contemporary-prairie-sp265172

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see https://www.houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
