Plan #487-6

Tudor Exterior - Front Elevation Plan #487-6 - Houseplans.com
  • 2878 sq ft
  • 3 beds
  • 2.5 baths
  • 55' wide
  • 56' deep


Plan Set
Reproducible Set
Single Set
Pier Post Beam
Right-Reading Reverse

House Features

  • Upstairs Bedrooms
  • Upstairs Master Bedrooms
  • Walk In Closet
  • Breakfast Nook
  • Kitchen Island
  • Walk In Pantry Cabinet Pantry
  • Mud Room
  • Den Office Study Computer
  • Hobby Rec Room Game Room
  • Upstairs Laundry
  • Great Room Living Room
  • Storage Area
  • Master Sitting Area
  • Bonus Play Flex Room
  • Wet Bar
  • Media Room
  • Oversized Garage
  • Friend S Entry
  • Covered Front Porch
  • Covered Rear Porch
  • Economical To Build
  • Suited For View Lot
  • Mud Room
  • Den Office Study Computer
  • Hobby Rec Room Game Room
  • Upstairs Laundry
  • Great Room Living Room
  • Storage Area
  • Master Sitting Area
  • Bonus Play Flex Room
  • Wet Bar
  • Media Room

Styles Classifications

  • Tudor
  • Traditional


Upper Floor Sq Ft 1630 sq ft
Main Floor Sq Ft 1248 sq ft
Total Sq Ft 2878 sq ft
Garage Sq Ft 812 sq ft
Porch Sq Ft 102 sq ft
Patios Sq Ft 235 sq ft
Height 34'
Depth 56'
Width 55'
Primary Pitch 10:12
Secondary Pitch 7:12
Roof Load 45# Total
Roof Type Architectural Comp
Roof Framing Manufactured Trusses
Main Ceiling Ft 9'
Upper Ceiling Ft 9'
Garage Ceiling Ft 10'
Floor Plan - Main Floor Plan
Floor Plan - Upper Floor Plan

In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.

To find out what documents you should expect with your house plans, see http://houseplans.com/whats-included.

In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.

Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.

Note: All sales on house plans are final. No refunds or exchanges can be given once your order has been fulfilled or once we have begun to customize a home plan to your specifications.
