Plan Description

This cottage focuses on an internal courtyard which is accessible from all the rooms on the first level. The high ceilings on the first two levels and the vaulted ceiling in the attic space make all the rooms feel very spacious. There are four bedrooms and four baths with adjoining living/dining and kitchen areas. Common areas are added to the 2nd and 3rd levels to give flexibility to each floor.
