Plan 405-284

Key Specs

2628
sq ft

5
Beds

2.5
Baths

2
Floors

2
Garages

Plan Description

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Modify this Plan

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

PRO BUILDERS:

Join the club and save 5% on your first order plus exclusive discounts and more.

JOIN FOR FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Full Specs & Features

Basic Features

Bedrooms : 5

Baths : 2.5

Stories: 2

Garages: 2

Dimension

Depth : 44' 4"

Height : 27' 6"

Width : 54'

Area

Total : 2628 sq/ft

First Floor: 1207 sq/ft

Second Floor: 1421 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 16:12

Roof Framing : Conventional

Roof Type : Asphalt

Exterior Wall Framing

Exterior Wall Finish : Brick/Stucco

Framing : Wood - 2x4

Bedroom Features

Fireplace

Formal Dining Room

Formal Living Room / Parlor

Upstairs Master Bedrooms

Kitchen Features

Breakfast Nook

Kitchen Island

Additional Room Features

Family Room Keeping Room

Vaulted / Cathedral Ceilings

Rooms

Bedroom 2:

147 sq/ft width 11' 6" x depth 12' 10"

Bedroom 2 Closet:

20 sq/ft width 8' 2" x depth 2' 6"

Bedroom 3:

143 sq/ft width 11' 6" x depth 12' 6"

Bedroom 3 Closet:

20 sq/ft width 8' 2" x depth 2' 6"

Bedroom 4:

141 sq/ft width 11' 4" x depth 12' 6"

Bedroom 4 Closet:

12 sq/ft width 5' 6" x depth 2' 4"

Breakfast Room:

151 sq/ft width 15' 2" x depth 10'

Coat Closet:

6 sq/ft width 2' 8" x depth 2' 4"

Dining Room:

157 sq/ft width 15' x depth 10' 6"

Family Room:

304 sq/ft width 19' x depth 16'

Foyer:

41 sq/ft width 10' 4" x depth 4'

Garage:

480 sq/ft width 20' x depth 24'

Half Bathroom:

6 sq/ft width 2' 3" x depth 2' 10"

Hall Closet:

6 sq/ft width 2' 3" x depth 2' 10"

Kitchen:

199 sq/ft width 15' 2" x depth 13' 2"

Laundry Room:

10 sq/ft width 10' 4" x depth 1'

Living Room:

161 sq/ft width 11' 6" x depth 14'

Master Bathroom:

156 sq/ft width 10' 5" x depth 15'

Master Bedroom:

238 sq/ft width 14' x depth 17'

Master Closet:

80 sq/ft width 9' 6" x depth 8' 6"

Master Sitting Area:

208 sq/ft width 13' x depth 16'
