Plan 47-657

Plan Description

Perfect in a wooded or mountainous setting, this home is a relaxing and versatile vacation hideaway. A deep deck sweeps up to the entry, while a balcony offers a great view from the upper-floor master bedroom. Inside, the living room enjoys a cozy fireplace and an open layout. The kitchen boasts a window over the sink that overlooks the side yard. The adjoining dining room revels in a view of the deck, which would make the perfect spot for a meal when the weather is nice. A secondary bedroom on the main floor is located just across the hall from a full bath. Upstairs, the master bedroom hosts a good-sized closet, a French door that leads out to a private balcony, and a large storage space. Another bedroom features three big windows and accesses two more storage areas.

This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features

Basic Features

Bedrooms : 3
Baths : 1.5
Stories: 2
Garages: 0


Depth : 36'
Height : 24'
Width : 24'


Total : 1073 sq/ft
First Floor: 672 sq/ft height 8'
Second Floor: 401 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Primary Pitch : 14:12
Roof Framing : Conventional
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Siding
Framing : Wood - 2x6 Wood - 2x4

Bedroom Features

Formal Dining Room
Formal Living Room / Parlor

Kitchen Features

Breakfast Nook

Additional Room Features


Outdoor Spaces

Covered Front Porch


3rd BR Closet:

11 sq/ft width 5' 9" x depth 2'

Basement Foundation:

672 sq/ft width 28' x depth 24'

Bathroom 2:

30 sq/ft width 5' 11" x depth 5' 2"

Bedroom 2:

124 sq/ft width 9' 1" x depth 13' 8"

Bedroom 2 Closet:

10 sq/ft width 2' x depth 5' 2"

Bedroom 3:

97 sq/ft width 9' 1" x depth 10' 9"

Bedroom 3 Closet:

10 sq/ft width 2' x depth 5' 2"

Crawlspace Foundation:

672 sq/ft width 28' x depth 24'

Dining Room:

68 sq/ft width 8' 1" x depth 8' 5"

Hall Bathroom:

48 sq/ft width 7' 4" x depth 6' 7"


65 sq/ft width 7' 10" x depth 8' 5"

Living Room:

172 sq/ft width 14' 6" x depth 11' 11"

Porch - Front:

192 sq/ft width 8' x depth 24'

Walk-In Closet:

19 sq/ft width 4' 1" x depth 4' 8"
