Plan 943-20

Photographs may show modified designs.
Plan 943-20

Key Specs


1606
sq ft

3
Beds

2
Baths

1
Floors

2
Garages

Plan Description


A lovely bay window jazzes up the exterior of this efficient plan. Vaulted ceilings over the main living areas make the home feel larger. The U-shaped kitchen, open to the dining area and family room, offers plenty of counter space and a handy snack bar. Private spaces are located on the right side, including the master suite with its private bathroom and walk-in closet. Two additional bedrooms share another full bath.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Floor Plans


Floor Plan - Main Floor Plan

Reverse

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2
Stories: 1
Garages: 2

Dimension

Depth : 61'
Height : 17' 9"
Width : 39'

Area

Total : 1606 sq/ft
First Floor: 1606 sq/ft height 8'
Garage: 440 sq/ft height 8'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 5:12
Roof Framing : Truss

Exterior Wall Framing

Exterior Wall Finish : Shingle/Siding
Framing : Wood - 2x6

Bedroom Features

Formal Dining Room
Formal Living Room / Parlor
Walk In Closet

Additional Room Features

Family Room Keeping Room
Vaulted / Cathedral Ceilings

Rooms

Bedroom 1:

105 sq/ft width 10' 2" x depth 10' 4"

Bedroom 2:

93 sq/ft width 10' 2" x depth 9' 2"

Dining Room:

91 sq/ft width 8' 4" x depth 11'

Family Room:

249 sq/ft width 18' 6" x depth 13' 6"

Garage:

408 sq/ft width 19' x depth 21' 6"

Hall Bathroom:

40 sq/ft width 5' x depth 8'

Hallway:

width 3' 2" x depth 0"

Kitchen:

122 sq/ft width 10' 2" x depth 12'

Living Room:

190 sq/ft width 13' x depth 14' 8"

Master Bathroom:

34 sq/ft width 5' x depth 6' 10"

Master Bedroom:

179 sq/ft width 13' 8" x depth 13' 2"

Master Closet:

34 sq/ft width 5' x depth 6' 10"

Utility Room:

34 sq/ft width 6' 4" x depth 5' 6"
