Plan 126-226

Photographs may show modified designs.
Plan 126-226

Plan Description


This prairie modern home is perfect for a corner lot and its facade, a blend of traditional and modern is an enduring style that will look good for years to come. Designed specifically for a narrow building site, it offers many sought after amenities in a compact footprint. It is well suited to outdoor living in good weather with easy access to the outdoors. The spacious Great Room living area is bright and cheerful and the main floor features 9'-0" ceilings throughout with the spectacular well-lit Atrium soaring to two stories in height.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2
Stories: 2
Garages: 2

Dimension

Depth : 41'
Height : 23' 9"
Width : 29' 6"

Area

Total : 1958 sq/ft
Garage : 362 sq/ft
Main Floor : 979 sq/ft
Patios : 112 sq/ft
Porch : 42 sq/ft
Upper Floor : 979 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Two storey high ceiling in the Atrium
Garage Ceiling : 9' 4"
Main Ceiling : 9'
Upper Ceiling Ft : 8'

Roof

Primary Pitch : 4/12
Roof Framing : Truss
Roof Load : 40
Roof Type : Standard

Exterior Wall Framing

Exterior Wall Finish : Siding & Stone
Framing : 2x6
Insulation : Fiberglass Batt

Bedroom Features

Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet

Kitchen Features

Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room
Mud Room
Upstairs Laundry

Garage Features

Side Entry Garage

Lot Characteristics

Suited For Corner Lot
Suited For Narrow Lot
Suited For View Lot

Outdoor Spaces

Covered Front Porch
Covered Rear Porch

More

Additional Half Bath
Economical To Build

Energy Efficient Features

Energy Efficient Design

What's included in this plan set


See a sample plan set
  • Floor Plans Including electrical
  • Foundation Plan
  • Cross Sections and other detail sections when required
  • Cabinet and Stair Details
  • Exterior Elevations - All four sides
  • Cover Page with artists rendering
  • Misc. Construction and Code Notes
*See important information before purchasing

Pricing


Plan Options

5 Copy Set

$840.00
5 printed plan sets mailed to you.

8 Copy Set

$912.00
8 printed plan sets mailed to you.

PDF Print Set

$968.00
A non-modifiable, print only PDF file

CAD Set

$1288.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Single Set

$732.00
One printed set for bidding purposes only. Not a legal building set for construction.
Foundation Options

Slab

$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Crawlspace

$236.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Basement

$316.00
Ideal for level lot, lower level of home partially or fully underground.

Wood 2x6

$0.00
Wood 2x6

*Options with a fee may take time to prepare. Please call to confirm.

Additional Options:

Right-Reading Reverse

$200.00
Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets

$40.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Additional Use License

$400.00
Additional Use License.

Audio Video Design

$80.00
Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$31.20
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Material List

$84.00
A list of building supplies needed to construct the infrastructure of your new house.

Mirror Reversed Sets

$40.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

Unlimited Use License

$1200.00
Unlimited Use License.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.

We offer a 90% credit when you upgrade from a set, that is not for construction, to a 5-Copy set (or greater).
