Plan Description


Four bedrooms fit nicely on the first floor of this 2,487-square-foot plan, with a 23 x 23 bonus room available to finish upstairs if more room is needed. Family-friendly touches include a mudroom with lockers and a large pantry, with the laundry room just steps away (but not in the way when entering from the three-car garage). A double-headed shower adds contemporary luxury to the master suite. Graceful tapered columns highlight the entrance on the exterior.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 4
Baths : 3.5
Stories: 1
Garages: 3

Dimension

Depth : 61'
Height : 28'
Width : 84'

Area

Total : 2487 sq/ft
Bonus : 529 sq/ft
Garage : 768 sq/ft
Main Floor : 2487 sq/ft
Porch : 497 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Living Room has 12' ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'

Roof

Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Secondary Pitch : 8:12

Exterior Wall Framing

Exterior Wall Finish : Siding
Framing : 2 x 4

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet

Kitchen Features

Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Mud Room
Unfinished Future Space

Garage Features

Side Entry Garage

Lot Characteristics

Suited For Corner Lot

Outdoor Spaces

Covered Front Porch
Covered Rear Porch
