Plan 928-89

Plan Description


The elegant Chesterfield by Visbeen Associates, Inc. boasts the best of English Tudor design as well as a floor plan tailored to modern living. The main level features an open-plan living and dining area adjacent to the family-friendly kitchen. A first-floor master suite offers both privacy and convenience. Two additional bedrooms on the upper level as well as another guest bedroom and family room on the optional lower level make this home a haven for larger families and guests, offering both convenience and comfort.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 3.5
Stories: 2
Garages: 2

Dimension

Depth : 56'
Height : 28' 2"
Width : 56' 1"

Area

Total : 2529 sq/ft
Basement Unfinished: 1079 sq/ft height 9'
First Floor: 1637 sq/ft height 9'
Second Floor: 892 sq/ft height 8'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Asphalt

Exterior Wall Framing

Exterior Wall Finish : Shingle
Framing : Wood - 2x4

Bedroom Features

Fireplace
Split Bedrooms
Walk In Closet

Kitchen Features

Breakfast Nook
Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Main Floor Laundry
Mud Room
Open Floor Plan
Unfinished Future Space
Vaulted / Cathedral Ceilings

Garage Features

Side Entry Garage

Outdoor Spaces

Courtyard
Covered Rear Porch
Deck

Rooms

Bedroom 2:

176 sq/ft width 15' x depth 11' 9"

Bedroom 3:

235 sq/ft width 15' 4" x depth 15' 4"

Bedroom 4:

191 sq/ft width 12' 3" x depth 15' 8"

Dining Room:

165 sq/ft width 10' 7" x depth 15' 8"

Family Room:

605 sq/ft width 39' 6" x depth 15' 4"

Garage:

624 sq/ft width 24' x depth 26'

Living Room:

276 sq/ft width 15' 8" x depth 17' 8"

Master Bedroom:

200 sq/ft width 15' 4" x depth 13' 1"

Office:

151 sq/ft width 11' 4" x depth 13' 4"

What's included in this plan set


See a sample plan set

Please note: If you are building a Visbeen Architects design in the state of Michigan, please give us a call to confirm availability. Construction in some areas of Michigan requires special permission from the Architect.

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.

*See important information before purchasing

Pricing


Plan Options

PDF Set

Best Value!
$1795.50
PDF plan sets are best for fast electronic delivery and inexpensive local printing.

CAD Set

$3595.50
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Foundation Options

Daylight Basement

$0.00
Ideal for sloping lot, lower level of home partially underground.

Wood 2x4

$0.00
Wood 2x4

*Options with a fee may take time to prepare. Please call to confirm.

Additional Options:

Right-Reading Reverse

$175.50
Choose this option to reverse your plans and to have the text and dimensions readable.

Audio Video Design

$90.00
Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$35.10
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design

$90.00
Receive an overlay sheet with suggested placement of lighting fixtures.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
