This 2,869 sq. ft. 3 bedroom 2.5 bath Ranch style plan is split -- with master suite on one side and children's bedrooms on the other. A porch wraps around the house from front to back. There is an office/library off the great room, a sun room at the front. The great room opens to the rear porch. Bedrooms 2 and 3 are connected through a Jack-and Jill bath with double vanities.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.
Exterior Elevations are scaled (1/4" and 1/8" = 1'-0") drawings of the front, rear, left, and right sides of the home.
Detailed Floor plans of the home accurately dimensioning the positioning of the walls, doors, windows, stairs, and permanent fixtures.
Foundation plan details the foot print of the home. Location and size of load points, stem walls, footings, pony walls, and floor joist.
Roof plans are typically truss planing, truss manufacturer will provide detail diagrams of truss's. In some cases the roof plans may be drawn as stick framed or have stick framing which will call out lumber sizes and spacing.
Cross Sections offer a cut away through the home showing your builder the correlation of building components.
Details indicate minimum CABO/IRC standards for construction of the home.
Electrical plan shows the schematic of the electrical layout. Most electricians want to discuss the options the home owner desires prior to bidding.
Mechanical and Detailed Plumbing plans are not included. These are site specific and are accomplished by those professionals.
All plans are prepared in compliance with the Uniform Building Code (ICBO) or the International Residential Code, a National Standard for residential construction at the time of completion.
