Plan Description

This European plan features brick, stone, and shake siding exterior with arched doors and windows and a 3-car garage. Upon entering the foyer, the Great Room with its vaulted ceiling is open to the kitchen and breakfast room which features an eat-at bar. The Master Suite has a 10' boxed ceiling and a huge walk-in closet. Bedrooms 2, 3, and 4 are located on the other side of the house with 2 full baths. There's also a bonus room located over the garage.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features

Basic Features

Bedrooms : 4
Baths : 3.5
Stories: 1
Garages: 3


Depth : 77' 8"
Height : 21' 9"
Width : 57' 4"


Total : 2413 sq/ft
Bonus: 332 sq/ft
First Floor: 2413 sq/ft height 9'
Garage: 762 sq/ft height 9'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Ceiling Details :
Main Ceiling : 9'


Primary Pitch : 12:12
Roof Framing : Stick
Roof Load : 45
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Stone Veneer
Framing : 2x4
Insulation : R-13

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet

Kitchen Features

Breakfast Nook
Eating Bar

Additional Room Features

Great Room Living Room

Garage Features

Front Entry Garage
Split Garage

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Outdoor Kitchen Grill
Screened Porch


Bedroom 2:

width 11' 2" x depth 11'

Bedroom 3:

width 11' 2" x depth 11'

Bedroom 4:

width 12' 8" x depth 11' 6"


width 10' 4" x depth 10' 6"


width 11' 10" x depth 12'


width 22' 4" x depth 21' 4"

Garage 2:

width 11' 4" x depth 22' 8"

Great Room:

width 17' 2" x depth 17' 2"


width 10' 4" x depth 11' 6"


width 11' 2" x depth 5' 4"

Master Bath:

width 9' 8" x depth 10' 4"

Master Bedroom:

width 13' 6" x depth 14'

Master Closet:

width 13' 6" x depth 13' 6"

Porch Front:

56 sq/ft

Porch Screened:

279 sq/ft width 27' 8" x depth 12'
