Plan 17-3336

Photographs may show modified designs.
Plan 17-3336

Plan Description


It's all about the kitchen in this rugged home, with space at the island to seat seven and a totally open dining nook just steps away. A large walk-in pantry holds groceries nearby. The great room also opens to the kitchen, with a fireplace creating cozy ambiance. A second fireplace warms up cool evenings on the grilling porch outside. Easy to reach on this level, the master suite includes private access to the bathroom. Two more bedrooms, another bath, and a loft offer more sleeping space upstairs.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2
Stories: 2
Garages: 0

Dimension

Depth : 61' 8"
Height : 24' 4"
Width : 36' 8"

Area

Total : 1705 sq/ft
First Floor: 1085 sq/ft height 9'
Porch: 2624 sq/ft
Second Floor: 620 sq/ft height 9'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Metal

Exterior Wall Framing

Exterior Wall Finish : Shingle/Siding
Framing : 2 x 4

Bedroom Features

Fireplace
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet

Kitchen Features

Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room
Loft
Main Floor Laundry
Open Floor Plan
Vaulted / Cathedral Ceilings

Outdoor Spaces

Balcony
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Wrap Around Porch

Rooms

Bathroom 1:

45 sq/ft width 9' x depth 5'

Bathroom 2:

45 sq/ft width 9' x depth 5'

Bedroom 2:

130 sq/ft width 11' 6" x depth 11' 4"

Bedroom 3:

145 sq/ft width 12' 6" x depth 11' 8"

Dining Room:

148 sq/ft width 13' 6" x depth 11'

Foyer:

61 sq/ft width 8' 4" x depth 7' 4"

Great Room:

317 sq/ft width 13' 6" x depth 23' 6"

Kitchen:

145 sq/ft width 11' 8" x depth 12' 6"

Loft:

97 sq/ft width 11' 6" x depth 8' 6"

Master Bedroom:

158 sq/ft width 12' 6" x depth 12' 8"

What's included in this plan set


See a sample plan set
  • Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
  • Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
  • Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
  • Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
  • Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
  • Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
  • Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
*See important information before purchasing

Pricing


Plan Options

PDF Set

Best Value!
$990.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.

5 Copy Set

$1080.00
5 printed plan sets mailed to you.

5 Copy and PDF Set

$1305.00
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing.

CAD Set

$1980.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Foundation Options

Crawlspace

$0.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Slab

$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Basement

$269.10
Ideal for level lot, lower level of home partially or fully underground.

Daylight Basement

$269.10
Ideal for sloping lot, lower level of home partially underground.

Wood 2x4

$0.00
Wood 2x4

Wood 2x6

$269.10
Wood 2x6

*Options with a fee may take time to prepare. Please call to confirm.

Additional Options:

Right-Reading Reverse

$179.10
Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets

$67.50
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design

$90.00
Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$35.10
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design

$90.00
Receive an overlay sheet with suggested placement of lighting fixtures.

Roof Framing Detail

$134.10
Get a detailed plan for your roof framing.
