Plan 23-2584

Photographs may show modified designs.
Plan 23-2584

Plan Description


Here's a sleek, modern plan that fits onto a narrow lot. On the lowest level, there's parking and storage space. One level up, main gathering spaces flow beautifully into one another. The kitchen offers casual seating at the island, where it's easy to maintain a conversation with people in the nearby family room and the open dining space. The larger living room sits near the front. Upstairs, three bedrooms share a spacious bathroom that boasts two sinks and a separate tub and shower. The laundry room is located conveniently nearby.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2
Stories: 2
Garages: 1

Dimension

Depth : 40'
Height : 33' 10"
Width : 26'

Area

Total : 1883 sq/ft
Basement Unfinished: 980 sq/ft
First Floor: 980 sq/ft
Garage: 331 sq/ft
Second Floor: 903 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12
Roof Framing : Truss
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x6

Bedroom Features

Walk In Closet

Kitchen Features

Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry

Additional Room Features

Family Room Keeping Room
Loft
Open Floor Plan
Upstairs Laundry

Outdoor Spaces

Balcony
Covered Front Porch

Rooms

Bedroom 2:

width 10' x depth 12'

Bedroom 3:

width 10' x depth 12'

Dining:

width 14' x depth 11'

Family Room:

width 13' x depth 12'

Garage:

331 sq/ft width 14' x depth 20' 8"

Kitchen:

width 11' x depth 12' 4"

Living Room:

width 14' x depth 15'

Master Bedroom:

width 14' x depth 12' 8"
