Plan Description


The second floor living and master wings of this compact modern home occupy two separate square, tall volumes linked via a low-profile entry way. The living wing floor slab is set on concrete piles, floating above the sloping ground of the wooded lot. The structure integrates into the natural setting, reducing its impact. The minimalist modern design palette combines concrete foundations with a timber-framed post and beam structure, wooden roof decks, steel hardware, stucco and cedar siding, and multiple tall windows that overlook the McKenzie River. The separate wings’ shed roofs lift in opposite directions, accommodating transom windows and affording panoramic views of the surrounding drama of forest, basalt cliffs, and river. In addition to the architectural drawings, this design comes with the following structural drawings: Foundation plan, floor framing plan, retaining walls and floor details, beam and pier details, shearwall plan, roof framing plan, and column details

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Floor Plans


Floor Plan - Main Floor

houseplans LOGO

BUILDER Advantage Program

PRO BUILDERS

Join the club and save 5% on your first order.
PLUS download exclusive discounts and more.

Floor Plan - Lower Floor

Floor Plan - Other Floor

Full Specs & Features


Basic Features

Bedrooms : 2
Baths : 2.5
Stories: 2
Garages: 2

Dimension

Depth : 26'
Height : 23'
Width : 54'

Area

Total : 1953 sq/ft
Garage : 621 sq/ft
Lower Floor : 657 sq/ft
Main Floor : 1296 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Ceiling height in main living area is 9' and slopes up to 11'
Main Ceiling : 9'

Roof

Primary Pitch : 1:12
Roof Framing : Stick

Exterior Wall Framing

Exterior Wall Finish : Stucco and Cedar Siding
Framing : 2x6
Insulation : R-21 and R-30

Bedroom Features

Main Floor Master Bedroom
Split Bedrooms
Walk In Closet

Kitchen Features

Eating Bar

Additional Room Features

Great Room Living Room
Mud Room
Storage Area

Garage Features

Detached Garage

Lot Characteristics

Suited For Sloping Lot
Suited For View Lot

Outdoor Spaces

Grill Deck Sundeck

What's included in this plan set


See a sample plan set
If you are building this plan in the state of Oregon, please call us before placing your order, restrictions may apply.
