Key Specs


2316
sq ft

3
Beds

2
Baths

1
Floors

3
Garages

Plan Description


Vaulted ceilings add to the expansive sense of spaciousness in this traditional single-level home. The entry and media/study (or home office) are vaulted, along with the great room, dining area and one of the bedrooms. Raised eating and conversation bars rim the spacious kitchen, which is open to the great room. A gas fireplace nestles into a corner at the rear.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Floor Plans


Floor Plan - Main Floor Plan

Reverse

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2
Stories: 1
Garages: 3

Dimension

Depth : 66'
Height : 22' 1"
Width : 72'

Area

Total : 2316 sq/ft
First Floor: 2316 sq/ft height 9'
Garage: 765 sq/ft height 9'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 7:12
Roof Framing : Truss
Roof Load : 25

Exterior Wall Framing

Exterior Wall Finish : Siding/Shingle
Framing : 2"x6"

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet

Kitchen Features

Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Master Sitting Area
Media Room
Mud Room

Garage Features

Front Entry Garage
Oversized Garage

Outdoor Spaces

Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck

More

Empty Nester

Code Compliance

Irc 2006

Structural Information Provided

Foundation Drawing
Structural 1st Floor Framing
Structural Roof Framing

Rooms

Bedroom 2:

158 sq/ft width 14' x depth 11' 4"

Bedroom 3:

168 sq/ft width 14' x depth 12'

Dining Room:

191 sq/ft width 14' x depth 13' 8"

Garage:

759 sq/ft width 33' x depth 23'

Great Room:

415 sq/ft width 24' x depth 17' 4"

Master Suite:

248 sq/ft width 14' 6" x depth 17' 2"

Media Room:

166 sq/ft width 13' 2" x depth 12' 8"
