Plan Description

An arched entry accented with elegant dual columns and flanked by charming dormers meshes cleanly with the smooth stucco and rock exterior of this offering. The sun room demands attention with its elegant French door entries, twin sky lights and quick access to three distinct areas of the home and the back yard. The screened porch is sure to be a hit with the beautiful atrium doors leading to the master suite and adjacent placement next to the kitchen. All ceilings 9 ft Stone step entry to front porch with 8 inch boxed columns and vaulted ceiling Foyer with 12 ft ceiling Bedroom 2/Study with 10 ft ceiling Dining room with 8 inch round columns and 10 ft ceiling Kitchen with 10 ft ceiling and desk area, bar open to Breakfast room with 10 ft ceiling, bay window and access to rear screened porch Great room with 10 ft ceiling, built-in media center and fireplace with French doors to Sun room Sun room accessed from screened porch and Great room with French doors-Bedroom 4 access too Master suite has 10 ft boxed ceiling, atrium doors to screened porch Master bath with his/hers closets, whirlpool tub, glass shower with seat and split vanities Side covered porch similar to front porch from garage Proposed upper bonus area Roof Framing: 2x6 Insulation Exterior Walls: R-13 Ceiling Minimum: R-30 Floor Minimum: R-19 Roof Designed Roof Load: 45-lbs. Psf lbs. psf Roof Pitch - Main: 8:12 Roof Pitch - Front Gable: 12:12 Roof Pitch - Porch: 5:12 Room Dimensions: Master Bath - 16/0 x 16/8 Master Suite - 16/8 x 16/8 Laundry - 12/10 x 5/11 Kitchen - 13/6 x 10/4 Nook - 13/6 x 9/6 Great Room - 21/0 x 17/0 Bedroom 4 - 15/4 x 12/0 Bedroom 3 - 11/6 x 12/0 Bedroom 2 - 11/0 x 13/10 Foyer - 7/4 x 10/11 Dining - 12/6 x 16/2 Garage - 20/4 x 25/6 Covered Side Porch - 16/4 x 8/0 Screened Porch - 13/6 x 15/0 Sun Room 21/0 x 8/8 Front Porch 31/6 x 8/0 (10' ceiling) Bonus Room - 32/9 x 26/10 (8' ceiling)
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features

Basic Features

Bedrooms : 4
Baths : 2.5
Stories: 1
Garages: 2


Depth : 59'
Height : 27'
Width : 85'


Total : 2742 sq/ft
Bonus : 916 sq/ft
Garage : 519 sq/ft
Main Floor : 2742 sq/ft
Porch : 620 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
