Plan Description


Through the double door entry is an impressive hexagonal, vaulted great room filled with windows showcasing a wraparound patio and gorgeous views. There are two fireplaces in the great room, one to be enjoyed in the living area and the other in the dining area shared with the covered patio. The left side of the house has a spacious utility room and a luxurious owners' suite. The owners' suite has its own sitting area with private fireplace, a large walk-in closet and a luxurious bathroom. The right side of the house has the separated bedrooms and a large bonus room with a separate entrance. The lower level garage is roomy enough for extra storage or a great work space.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2
Stories: 1
Garages: 1

Dimension

Depth : 63'
Height : 20' 1"
Width : 75'

Area

Total : 3389 sq/ft
Garage : 804 sq/ft
Main Floor : 2585 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 6/12
Roof Framing : Truss
Roof Load : 30

Exterior Wall Framing

Exterior Wall Finish : Shingle/Stone
Framing : 2x6

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet

Kitchen Features

Breakfast Nook
Eating Bar

Additional Room Features

Main Floor Laundry
Master Sitting Area
Play Flex Room

Garage Features

Front Entry Garage
Garage Under

Lot Characteristics

Suited For Sloping Lot
Suited For View Lot

Outdoor Spaces

Wrap Around Porch

More

Unusual Shape

What's included in this plan set


See a sample plan set
Please note, if ordering a PDF set, it is not-modifiable. The CAD set is best for making local modifications

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
  • Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
  • Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
  • Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
  • Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
  • Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
  • Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
  • Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
  • Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
  • Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
*See important information before purchasing
