Main Floor: 9' ceiling everywhere, but approx. 18' ceiling in family room. Foyer with 2 coat closets, media room, kitchen, dining room, family room, shower room, bedroom no. 5 (or home office), laundry room and mud room. Second Floor: Master suite, computer room, 3 secondary bedrooms, full bathroom. Triple car garage with access to full unfinished basement. Many foundation options available. Cape Cod style home with panoramic view and a very large covered deck. 9' ceiling througout the main floor, but family room with 18' ceiling. Foyer with 2 coat closets. Media room (or play room) next to kitchen. Kitchen with pantry and large kitchen island. Dining room with patio-doors leading to large covered terrasse (large deck). Family room with fireplace and built-ins. Practical access to shower room from deck and bedroom 5 (or home office). Laundry room next to mud room. 3-car garage with access to full unfinished basement.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350
Full Specs & Features
Depth : 61' 4"
Height : 28' 10"
Main Floor : 1873 sq/ft
Upper Floor : 1880 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Primary Pitch : 8:12
Roof Framing : Truss
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Covered Front Porch
Covered Rear Porch
