Plan 23-294

Photographs may show modified designs.
Plan 23-294

Plan Description

This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features

Basic Features

Bedrooms : 5
Baths : 3.5
Stories: 2
Garages: 3


Depth : 51'
Height : 36'
Width : 95'


Total : 4147 sq/ft
First Floor: 2502 sq/ft height 9'
Garage: 789 sq/ft
Second Floor: 1645 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Main Ceiling : 9'
Upper Ceiling Ft : 8'


Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 12:12

Exterior Wall Framing

Exterior Wall Finish : Stone
Framing : 2"x6"

Bedroom Features

Main Floor Master Bedroom
Walk In Closet

Kitchen Features

Breakfast Nook
Kitchen Island

Additional Room Features


Garage Features

Side Entry Garage

Lot Characteristics

Suited For Corner Lot
Suited For View Lot

Outdoor Spaces

Covered Front Porch
Covered Rear Porch


3rd BR Closet:

15 sq/ft width 7' 6" x depth 2'

Bathroom 2:

78 sq/ft width 14' 4" x depth 5' 6"

Bathroom 3:

124 sq/ft width 11' 4" x depth 11'

Bedroom 2:

207 sq/ft width 14' 4" x depth 14' 6"

Bedroom 2 Closet:

15 sq/ft width 7' 6" x depth 2'

Bedroom 3:

149 sq/ft width 14' x depth 10' 8"

Bedroom 3 Closet:

15 sq/ft width 7' 6" x depth 2'

Bedroom 4:

168 sq/ft width 11' 6" x depth 14' 8"

Bedroom 4 Closet:

37 sq/ft width 6' x depth 6' 4"

Bedroom 5:

176 sq/ft width 16' x depth 11'

Breakfast Room:

138 sq/ft width 14' 4" x depth 9' 8"

Dining Room:

192 sq/ft width 13' x depth 14' 10"


140 sq/ft width 14' x depth 10'


713 sq/ft width 23' x depth 31'

Hall Closet:

5 sq/ft width 2' 6" x depth 2'


164 sq/ft width 12' 8" x depth 13'

Living Room:

306 sq/ft width 18' x depth 17'

Master Bathroom:

190 sq/ft width 13' x depth 14' 8"

Master Bedroom:

322 sq/ft width 14' 8" x depth 22'

Master Closet:

91 sq/ft width 13' x depth 7'

Porch - Front:

316 sq/ft width 48' 8" x depth 6' 6"

Porch - Left:

71 sq/ft width 4' 8" x depth 15' 4"

Porch - Rear:

122 sq/ft width 14' 8" x depth 8' 4"

Powder Room:

30 sq/ft width 7' 8" x depth 4'


216 sq/ft width 13' x depth 16' 8"

Utility Room:

56 sq/ft width 7' 8" x depth 7' 4"

What's included in this plan set

See a sample plan set

Exterior Elevations (front, rear, left & right sides) typically include:
  • Floor and ceiling heights
  • Dimensions of standard windows
  • Dimensions of roof overhangs
  • Location of all needed flashings
  • Height and location of foundation indicated in dashed lines
  • Type of finishing and textures
  • Dimension and height of chimney
Foundation plans typically include:
  • All exterior and interior dimensions
  • Thickness of foundation walls (if variable)
  • All the structures needed to hold the first level, columns with load applications, beam sizes, variations in floor joists and their exact location
  • Location of stairwell
  • Location and sizes of windows
  • Location and dimensions of footings (where applicable and required)
Floor plan(s) typically include:
  • All interior and exterior dimensions
  • Location and sizes of doors and windows
  • Types of interior doors that correspond to a schedule
  • Indication of the structure above (second floor or roof)
  • Location of columns, beams and floor joists, including dimensions
  • Indication of details that are available on other pages
Roof plans typically include:
  • Location of all the different trusses needed
  • The general overcharge of the roof compared to the floor footprint underneath
  • Location of ridges and valleys
Building cross-section(s) and truss details typically include:
  • All the different floor and ceiling heights
  • Dimensions and design of trusses
  • Dimensions and details of overhand
  • Roof pitch on all truss sections
Construction details typically include:
  • Roof sections
  • Sections of concrete wall with wood connection
  • Section of walls with particulars called out
  • Section of concrete porch and connection with wood frame
  • Foundation particulars in the garage entrance
  • Components of certain types of walls (ex: between garage and living quarters)
Typical wall sections typically include;
  • All the details and components needed in the construction of a house, including window section in a typical wall, connection between floor and exterior wall with their components, type of beam used.
  • Note: This plan does not include an electrical layout.
