Just 629 square feet of living space, this tiny house plan offers two bedrooms in a compact footprint. The front entrance takes you directly to the living room which is open to the eat-in kitchen. Open floor plan layout and a 9’ ceiling are very convenient and appreciated in smaller home models. A good size storage closet is also located near the front entrance and the secondary bedroom. The master bedroom’s closet is showing a wardrobe, which is very practical because it offers various storage options. In addition, this master bedroom offers direct access to the bathroom through a pocket door. The second bedroom also suggests a wardrobe (shown on our floor plan). The addition of a conventional closet is also easily feasible. A full bathroom with shower-bath combo and a stacked washer and dryer are designed to maximize square foot and investment.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.
