Plan Description


This home designed in classic a Northern New Mexico adobe style, with a graceful private courtyard and plenty of privacy. It has thoughtful details like kiva fireplaces, exposed vigas in the living room and master bedroom, and traditional spiral log columns at the portáls (covered porches). Suitable as family or vacation home, it also has modern amenities: well insulated walls, performance windows, and a trussed roof construction that lends itself to central air if desired.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2
Stories: 1
Garages: 1

Dimension

Depth : 50' 2"
Height : 13'
Width : 57' 2"

Area

Total : 1618 sq/ft
Garage : 543 sq/ft
Main Floor : 1618 sq/ft
Porch : 494 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Garage Ceiling : 9'
Main Ceiling : 9'

Roof

Primary Pitch : Flat
Roof Framing : Truss
Roof Type : Flat w/parapet
Secondary Pitch : 2%

Exterior Wall Framing

Exterior Wall Finish : Stucco
Framing : 2x6
Insulation : R-33 closed-cell foam + rigid insulation sheathing

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom

Kitchen Features

Breakfast Nook

Additional Room Features

Den Office Study Computer
Main Floor Laundry

Garage Features

Carport Porte Cochere
Detached Garage

Entryway

Friend S Entry

Lot Characteristics

Suited For Corner Lot

Outdoor Spaces

Courtyard
Covered Rear Porch
Wrap Around Porch
