Plan 70-627

Photographs may show modified designs.
Plan 70-627

Plan Description


This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 4
Baths : 2.5
Stories: 2
Garages: 3

Dimension

Depth : 61' 8"
Height : 28'
Width : 58' 4"

Area

Total : 2448 sq/ft
First Floor: 1616 sq/ft height 9'
Second Floor: 832 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 8:12

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding
Framing : 2"x6"

Bedroom Features

Main Floor Master Bedroom
Walk In Closet

Kitchen Features

Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room
Loft
Sunroom
Unfinished Future Space

Garage Features

Oversized Garage
Side Entry Garage

Lot Characteristics

Suited For Corner Lot
Suited For View Lot

Outdoor Spaces

Balcony
Covered Front Porch
Screened Porch

Rooms

3rd BR Closet:

27 sq/ft width 4' 4" x depth 6' 4"

Basement Foundation:

1968 sq/ft width 57' 4" x depth 34' 4"

Bedroom 2:

205 sq/ft width 15' x depth 13' 8"

Bedroom 2 Closet:

40 sq/ft width 5' 10" x depth 7'

Bedroom 3:

177 sq/ft width 14' 10" x depth 12'

Bedroom 3 Closet:

40 sq/ft width 5' 10" x depth 7'

Bedroom 4:

146 sq/ft width 11' x depth 13' 4"

Bedroom 4 Closet:

16 sq/ft width 2' 2" x depth 7' 8"

Breakfast Room:

132 sq/ft width 11' 4" x depth 11' 8"

Dining Room:

124 sq/ft width 11' x depth 11' 4"

Foyer:

41 sq/ft width 7' 4" x depth 5' 8"

Garage:

718 sq/ft width 21' 8" x depth 33' 2"

Gathering Room:

251 sq/ft width 13' 4" x depth 18' 10"

Hall:

83 sq/ft width 26' 4" x depth 3' 2"

Hall Bathroom:

70 sq/ft width 6' x depth 11' 8"

Hall Closet:

9 sq/ft width 4' 8" x depth 2'

Kitchen:

128 sq/ft width 11' x depth 11' 8"

Laundry Room:

64 sq/ft width 6' x depth 10' 10"

Master Bathroom:

110 sq/ft width 10' x depth 11'

Master Bedroom:

205 sq/ft width 15' x depth 13' 8"

Master Closet:

49 sq/ft width 6' x depth 8' 4"

Porch - Front:

140 sq/ft width 20' x depth 7'

Powder Room:

36 sq/ft width 5' x depth 7' 4"

Slab Foundation:

808 sq/ft width 22' 8" x depth 35' 8"

Sun Room:

112 sq/ft width 9' 8" x depth 11' 8"

What's included in this plan set


See a sample plan set
  • Cover sheet with front rendering
  • Foundation and floor plans at 1/4" = 1' scale
  • Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
  • Building sections and details as required to construct the individual design
  • Interior elevation of cabinets at 1/4" = 1' scale
  • Roof plans
  • Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
  • Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
  • Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
*See important information before purchasing

Pricing


Plan Options

5 Copy Set

$913.50
5 printed plan sets mailed to you.

8 Copy Set

$954.90
8 printed plan sets mailed to you.

PDF Set

Best Value!
$1147.50
PDF plan sets are best for fast electronic delivery and inexpensive local printing.

Reproducible Set

$1147.50
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

CAD Set

$1818.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Foundation Options

Basement

$0.00
Ideal for level lot, lower level of home partially or fully underground.

Crawlspace

$301.50
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Slab

$301.50
Ideal for level lot, single layer concrete poured directly on grade.

*Options with a fee may take time to prepare. Please call to confirm.

Additional Options:

Right-Reading Reverse

$301.50
Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets

$58.50
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design

$90.00
Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$35.10
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design

$90.00
Receive an overlay sheet with suggested placement of lighting fixtures.

Mirror Reversed Sets

$49.50
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.
