Plan 70-693

Key Specs


Plan Sq Ft

2787
sq ft

Plan Bedrooms

4
Beds

Plan Bathrooms

2.5
Baths

Plan Floors

1
Floors

Plan Garages

3
Garages

Plan Description


This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Floor Plans


Floor Plan - Lower Floor

Reverse

BUILDER Advantage Program

PRO BUILDERS:

Join the club and save 5% on your first order plus exclusive discounts and more.

JOIN FOR FREE

Click to Get Your Trend Report

Floor Plan - Main Floor

Reverse

Full Specs & Features


Basic Features

Bedrooms : 4
Baths : 2.5
Stories: 1
Garages: 3

Dimension

Depth : 64'
Height : 22'
Width : 50'

Area

Total : 2787 sq/ft
Basement Living: 1160 sq/ft
First Floor: 1677 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding
Framing : 2"x6"

Bedroom Features

Split Bedrooms
Walk In Closet

Additional Room Features

Hobby Rec Room Game Room
Storage Area

Garage Features

Oversized Garage

Lot Characteristics

Suited For Narrow Lot
Suited For Sloping Lot
Suited For View Lot

Outdoor Spaces

Covered Front Porch
Grill Deck Sundeck

Rooms

Bedroom 2:

124 sq/ft width 11' 4" x depth 11'

Bedroom 2 Closet:

3 sq/ft width 4' 2" x depth 9"

Bedroom 3:

147 sq/ft width 13' x depth 11' 4"

Bedroom 3 Closet:

17 sq/ft width 8' 10" x depth 2'

Bedroom 4:

150 sq/ft width 12' 6" x depth 12'

Bedroom 4 Closet:

21 sq/ft width 10' 8" x depth 2'

Deck:

169 sq/ft width 14' 6" x depth 11' 8"

Dining Room:

204 sq/ft width 13' 4" x depth 15' 4"

Foyer:

82 sq/ft width 6' x depth 13' 10"

Game Room:

440 sq/ft width 27' 6" x depth 16'

Garage:

744 sq/ft width 31' x depth 24'

Hall:

18 sq/ft width 3' 8" x depth 5'

Hall Bathroom:

66 sq/ft width 9' x depth 7' 5"

Hall Closet:

8 sq/ft width 2' x depth 4'

Kitchen:

135 sq/ft width 11' 4" x depth 12'

Laundry Room:

35 sq/ft width 5' 8" x depth 6' 4"

Master Bathroom:

109 sq/ft width 8' 3" x depth 13' 3"

Master Bedroom:

211 sq/ft width 15' 6" x depth 13' 8"

Master Closet:

61 sq/ft width 9' x depth 6' 10"

Pantry:

6 sq/ft width 2' x depth 3'

Porch - Front:

234 sq/ft width 18' x depth 13'

Sun Room:

155 sq/ft width 13' 4" x depth 11' 8"

Wet Bar:

86 sq/ft width 11' 6" x depth 7' 6"

What's included in this plan set


See a sample plan set
  • Cover sheet with front rendering
  • Foundation and floor plans at 1/4" = 1' scale
  • Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
  • Building sections and details as required to construct the individual design
  • Interior elevation of cabinets at 1/4" = 1' scale
  • Roof plans
  • Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
  • Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
  • Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
*See important information before purchasing

Pricing


Plan Options

5 Copy Set

$864.80
5 printed plan sets mailed to you.

8 Copy Set

$897.60
8 printed plan sets mailed to you.

PDF Set

Best Value!
$1081.60
PDF plan sets are best for fast electronic delivery and inexpensive local printing.

Reproducible Set

$1081.60
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

CAD Set

$1729.60
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation Options

Crawlspace

$268.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Slab

$268.00
Ideal for level lot, single layer concrete poured directly on grade.

*Options with a fee may take time to prepare. Please call to confirm.

Additional Options

Right-Reading Reverse

$268.00
Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets

$52.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design

$80.00
Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$31.20
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Mirror Reversed Sets

$44.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.
