Plan 17-2416

Photographs may show modified designs.
Plan 17-2416

Plan Description


This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2.5
Stories: 2
Garages: 2

Dimension

Depth : 71'
Height : 34' 3"
Width : 53' 10"

Area

Total : 2930 sq/ft
Bonus: 249 sq/ft height 8'
First Floor: 1865 sq/ft height 9'
Garage: 544 sq/ft
Porch: 399 sq/ft
Second Floor: 1065 sq/ft height 8'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'
Upper Ceiling Ft : 8'

Roof

Primary Pitch : 0:0
Roof Framing : stick
Roof Load : 45
Roof Type : shingle

Exterior Wall Framing

Exterior Wall Finish : Shingle/Stone
Framing : 2"x4"
Insulation : R13

Bedroom Features

Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet

Kitchen Features

Breakfast Nook
Butler's Pantry
Eating Bar
Kitchen Island

Additional Room Features

Den Office Study Computer
Great Room Living Room
Loft
Main Floor Laundry
Media Room
Play Flex Room
Storage Area
Unfinished Future Space

Outdoor Spaces

Balcony
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck

More

Jack & Jill Bath

Rooms

Bedroom 2:

140 sq/ft width 12' x depth 11' 8"

Bedroom 3:

133 sq/ft width 11' x depth 12' 2"

Bonus Room - Unfinished:

234 sq/ft width 16' 4" x depth 14' 4"

Breakfast Nook:

136 sq/ft width 13' 8" x depth 10'

Dining Room:

140 sq/ft width 12' x depth 11' 8"

Foyer:

99 sq/ft width 8' 6" x depth 11' 8"

Garage:

462 sq/ft width 22' x depth 21'

Great Room:

375 sq/ft width 24' 6" x depth 15' 4"

Grilling Porch:

198 sq/ft width 24' 10" x depth 8'

Home Theater:

246 sq/ft width 17' x depth 14' 6"

Kitchen:

221 sq/ft width 17' 6" x depth 12' 8"

Master Bathroom:

143 sq/ft width 10' 6" x depth 13' 8"

Master Suite:

259 sq/ft width 18' 6" x depth 14'

Master Walk-In Closet:

91 sq/ft width 10' 6" x depth 8' 8"

What's included in this plan set


See a sample plan set
  • Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
  • Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
  • Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
  • Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
  • Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
  • Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
  • Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
*See important information before purchasing

Pricing


Plan Options

PDF Set

Best Value!
$1215.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.

5 Copy Set

$1305.00
5 printed plan sets mailed to you.

5 Copy and PDF Set

$1530.00
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing.

CAD Set

$2430.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Foundation Options

Crawlspace

$0.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Slab

$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Basement

$269.10
Ideal for level lot, lower level of home partially or fully underground.

Daylight Basement

$269.10
Ideal for sloping lot, lower level of home partially underground.

Wood 2x4

$0.00
Wood 2x4

Wood 2x6

$269.10
Wood 2x6

*Options with a fee may take time to prepare. Please call to confirm.

Additional Options:

Right-Reading Reverse

$179.10
Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets

$67.50
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design

$90.00
Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$35.10
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design

$90.00
Receive an overlay sheet with suggested placement of lighting fixtures.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
