Plan Description

This craftsman charmer packs a lot of punch into every inch of this home. • The open-concept floor plan features a kitchen with unique center island that overlooks the great room and adjacent dining room. • Cathedral ceilings and fireplace are found in the great room. • 10’ ceilings are found throughout the rest of the main floor. • Three bedrooms, including a master suite with step ceiling and walk-in closet are found on the second level. • Flex space for storage is also found upstairs. • A mother-in-law’s suite is located just off the right of the entry with walk-in closet. • A screen porch off the back is accessed through the dining area and creates another living space for the family.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features

Basic Features

Bedrooms : 4
Baths : 3
Stories: 2
Garages: 2


Depth : 73'
Height : 29' 8"
Width : 41'


Total : 3011 sq/ft
First Floor: 1626 sq/ft
Garage: 566 sq/ft
Second Floor: 1385 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Ceiling Details : Grt Rm/Rear Porch Cathedral, Loft 10', Master Bdrm 10' Step.
Lower Ceiling : 8'
Main Ceiling : 10'
Upper Ceiling Ft : 9'


Primary Pitch : 12:12
Roof Framing : Truss
Roof Load : 47 psf
Roof Type : Asphalt
Secondary Pitch : 8:12

Exterior Wall Framing

Exterior Wall Finish : Shingle/Siding
Framing : 2x6

Bedroom Features

Upstairs Master Bedrooms
Walk In Closet

Kitchen Features

Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room
Mud Room
Storage Area
Unfinished Future Space
Upstairs Laundry

Garage Features

Front Entry Garage

Lot Characteristics

Suited For Corner Lot
Suited For Narrow Lot

Outdoor Spaces

Covered Front Porch
Screened Porch


Economical To Build


Bath 2:

64 sq/ft width 6' 8" x depth 9' 8"

Bedroom 2:

158 sq/ft width 11' x depth 14' 4"

Bedroom 2 Closet:

23 sq/ft width 4' 6" x depth 5'

Bedroom 3:

187 sq/ft width 14' x depth 13' 4"

Bedroom 3 Closet:

13 sq/ft width 6' 8" x depth 2'

Bedroom 4:

161 sq/ft width 11' x depth 14' 8"

Bedroom 4 Closet:

13 sq/ft width 2' x depth 6' 8"

Covered Front Porch:

227 sq/ft width 17' x depth 13' 4"

Dining Area:

160 sq/ft width 13' 4" x depth 12'

First Level Bath:

75 sq/ft width 8' 8" x depth 8' 8"


80 sq/ft width 5' 4" x depth 15'


566 sq/ft width 23' x depth 23' 8"

Great Room:

350 sq/ft width 16' 8" x depth 21'

Hall Closet:

10 sq/ft width 2' x depth 5'


182 sq/ft width 13' 4" x depth 13' 8"

Linen Closet:

6 sq/ft width 2' x depth 3'

Living Room:

42 sq/ft width 7' x depth 6'


127 sq/ft width 8' 8" x depth 14' 8"

Master Bath:

94 sq/ft width 10' 4" x depth 9' 4"

Master Bedroom:

width 14' x depth 16'

Master Closet:

152 sq/ft width 20' 4" x depth 16'

Mud Room:

36 sq/ft width 6' x depth 6'

Mud Room Closet:

12 sq/ft width 2' x depth 6'


28 sq/ft width 5' x depth 5' 8"

Screened Porch:

240 sq/ft width 15' x depth 16'


256 sq/ft width 13' x depth 19' 8"
