Plan 117-102

Photographs may show modified designs.
Plan 117-102

Plan Description


This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2
Stories: 2
Garages: 0

Dimension

Depth : 44'
Height : 26' 3"
Width : 56'

Area

Total : 3303 sq/ft
First Floor: 1901 sq/ft height 8' 9"
Second Floor: 1402 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Upper Ceiling Ft : 8'

Roof

Primary Pitch : 14:12
Roof Framing : Conventional
Secondary Pitch : 6:12

Exterior Wall Framing

Exterior Wall Finish : Log
Framing : Log

Bedroom Features

Upstairs Master Bedrooms
Walk In Closet

Kitchen Features

Kitchen Island
Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer
Loft

Lot Characteristics

Suited For Sloping Lot
Suited For View Lot

Outdoor Spaces

Balcony

More

Suited For Vacation Home

Rooms

Deck:

92 sq/ft width 16' 9" x depth 5' 6"

Foyer:

135 sq/ft width 11' 4" x depth 12'

Kitchen:

228 sq/ft width 19' x depth 12'

Living Room:

460 sq/ft width 23' x depth 20'

Master Suite:

376 sq/ft width 15' 8" x depth 24'

What's included in this plan set


See a sample plan set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*See important information before purchasing

Pricing


Plan Options

Reproducible Set

$880.00
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

5 Copy Set

$960.00
5 printed plan sets mailed to you.

CAD Set

$1040.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

PDF Set

Best Value!
$1040.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Foundation Options

Daylight Basement

$0.00
Ideal for sloping lot, lower level of home partially underground.

Slab

$0.00
Ideal for level lot, single layer concrete poured directly on grade.

*Options with a fee may take time to prepare. Please call to confirm.

Additional Options:

Right-Reading Reverse

$80.00
Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets

$40.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design

$80.00
Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$31.20
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design

$160.00
Receive an overlay sheet with suggested placement of lighting fixtures.
