Plan Description


Wooden beams and columns grace the outside of this country French/craftsman inspired ranch home. Details that grab your attention abound in this home and start as soon as you enter with a direct view into the great room. Here you’ll be impressed with the beamed ceiling, fireplace and open floor plan that allows direct access to the kitchen. A formal dining room with tray ceiling is found to the left of the entry while a spacious den with coffered ceilings is located to the right. The bedroom wing is found on the right side of the home and includes a large master suite with spacious walk-in closet and Jacuzzi tub. Two additional bedrooms, each with private bathroom is located to the front of the home. A four-stall, split-load garage completes the home.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 3.5
Stories: 1
Garages: 4

Dimension

Depth : 71' 4"
Height : 29'
Width : 114' 8"

Area

Total : 3794 sq/ft
First Floor: 3794 sq/ft
Garage: 1595 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : 9'. Entry 11', Din Rm 12' Tray, Kitch 11'-6" Coffered, Nook 11'-6" Step, Grt Rm 13' Flat, Master Bdrm 10' Step
Lower Ceiling : 10'

Roof

Primary Pitch : 10:12
Roof Framing : Truss
Roof Load : 47 psf
Roof Type : Asphalt
Secondary Pitch : 8:12

Exterior Wall Framing

Exterior Wall Finish : Stone, Shake, Siding
Framing : 2x6

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet

Kitchen Features

Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Mud Room
Sunroom
Unfinished Future Space

Garage Features

Split Garage

Lot Characteristics

Suited For Corner Lot

Outdoor Spaces

Covered Front Porch
Screened Porch

Rooms

Bedroom 2:

width 14' x depth 13'

Bedroom 3:

width 13' x depth 13'

Breakfast Nook:

width 15' 6" x depth 15' 4"

Deck:

width 16' 4" x depth 9' 6"

Den:

width 15' x depth 17' 8"

Dining Room:

width 13' 8" x depth 15'

Garage 1:

width 32' 8" x depth 27'

Garage 2:

width 24' x depth 27' 8"

Great Room:

width 20' x depth 18' 8"

Kitchen:

width 15' 6" x depth 16'

Master Bedroom:

width 16' x depth 19' 6"

Porch Front:

348 sq/ft

Screened Porch:

221 sq/ft width 17' x depth 13'

What's included in this plan set


See a sample plan set
  • Cover sheet with front rendering
  • Foundation and floor plans at 1/4" = 1' scale
  • Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
  • Building sections and details as required to construct the individual design
  • Interior elevation of cabinets at 1/4" = 1' scale
  • Roof plans
  • Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
  • Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
  • Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
*See important information before purchasing

Pricing


Plan Options

5 Copy Set

$1400.40
5 printed plan sets mailed to you.

8 Copy Set

$1467.90
8 printed plan sets mailed to you.

PDF Set

Best Value!
$1844.10
PDF plan sets are best for fast electronic delivery and inexpensive local printing.

Reproducible Set

$1844.10
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

CAD Set

$2936.70
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Foundation Options

Basement

$0.00
Ideal for level lot, lower level of home partially or fully underground.

Crawlspace

$265.50
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Slab

$265.50
Ideal for level lot, single layer concrete poured directly on grade.

*Options with a fee may take time to prepare. Please call to confirm.

Additional Options:

Right-Reading Reverse

$265.50
Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets

$45.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design

$90.00
Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$35.10
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design

$180.00
Receive an overlay sheet with suggested placement of lighting fixtures.

Mirror Reversed Sets

$36.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.
