Plan 120-149

Photographs may show modified designs.
Plan 120-149

Plan Description


This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features


Basic Features

Bedrooms : 3
Baths : 2
Stories: 2
Garages: 2

Dimension

Depth : 45' 6"
Height : 18'
Width : 52' 11"

Area

Total : 1858 sq/ft
First Floor: 1485 sq/ft height 9'
Second Floor: 373 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding
Framing : 2"x4"

Bedroom Features

Main Floor Master Bedroom
Walk In Closet

Kitchen Features

Breakfast Nook
Kitchen Island

Additional Room Features

Family Room Keeping Room

Garage Features

Detached Garage
Rear Garage

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Covered Front Porch
Covered Rear Porch

Rooms

3rd BR Closet:

13 sq/ft width 6' 6" x depth 2'

Basement Foundation:

2090 sq/ft width 52' 11" x depth 39' 6"

Bathroom 2:

50 sq/ft width 10' x depth 5'

Bedroom 2:

104 sq/ft width 10' x depth 10' 5"

Bedroom 2 Closet:

13 sq/ft width 6' 6" x depth 2'

Bedroom 3:

104 sq/ft width 10' x depth 10' 5"

Bedroom 3 Closet:

13 sq/ft width 6' 6" x depth 2'

Breakfast Room:

120 sq/ft width 10' x depth 12'

Crawlspace Foundation:

2090 sq/ft width 52' 11" x depth 39' 6"

Dining Room:

157 sq/ft width 12' 5" x depth 12' 8"

Foyer:

67 sq/ft width 6' 3" x depth 10' 9"

Garage:

458 sq/ft width 21' 5" x depth 21' 5"

Gathering Room:

306 sq/ft width 18' x depth 17'

Hall:

28 sq/ft width 9' 5" x depth 3'

Kitchen:

165 sq/ft width 11' 9" x depth 14' 1"

Master Bathroom:

160 sq/ft width 12' 8" x depth 12' 8"

Master Bedroom:

213 sq/ft width 15' 2" x depth 14' 1"

Master Closet:

35 sq/ft width 7' 2" x depth 5'

Porch - Front:

247 sq/ft width 41' 3" x depth 6'

Porch - Left:

24 sq/ft width 3' 6" x depth 7'

Porch - Rear:

91 sq/ft width 13' x depth 7'

Slab Foundation:

2090 sq/ft width 52' 11" x depth 39' 6"

Utility Room:

61 sq/ft width 9' 2" x depth 6' 8"
