Plan Description

Each unit is 2705 sqft each. Ideally suited for a beach front lot, or anywhere there's a view, this dramatic design utilizes traditional construction of an exterior ICF wall with a stucco finish. All windows are double insulated, Low-E units providing a weather tight, highly efficient exterior wall. The deep, covered terraces provide protection from harmful solar gain, while allowing spectacular views of the skyline. Each of the 3 generous 2,700 sf units offer a dramatic dropped ceiling entry foyer with adjacent powder room leading to a stunning great room/kitchen entertaining area. The living area separates the master suite from the secondary 2 bedrooms each with private bath. All rooms have direct, open access to the curvilinear terraces which are separated into 3 distinct areas by decorative structural screen-walls. A separate covered deck provides a private outdoor area adjacent to the master bedroom.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features

Basic Features

Bedrooms : 9
Baths : 9
Stories: 3
Garages: 0


Depth : 37'
Height : 37'
Width : 99' 6"


Total : 8115 sq/ft
Decks : 2607 sq/ft
Lower Floor : 2705 sq/ft
Main Floor : 2705 sq/ft
Upper Floor : 2705 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Lower Ceiling : 8' 6"
Main Ceiling : 9'


Roof Framing : WD. TRUSS
Roof Type : FLAT TRUSS

Exterior Wall Framing

Exterior Wall Finish : STUCCO
Framing : ICF
Insulation : ICF, R30

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet

Kitchen Features

Eating Bar

Additional Room Features

Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Storage Area

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Grill Deck Sundeck
Wrap Around Porch


Economical To Build
Suited For Vacation Home

What's included in this plan set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
