The building is designed as a multi family unit with a central entry. Open decks and expansive windows make for generous living areas. Natural light floods the units from multiple directions offering natural ventilation and open vistas.
The building is shown with exterior treatments of masonry, wood siding and stucco. Exterior walls are designed for “green wall” construction typical with insulated (R30) ICF walls. The flat roof design is suitable for solar panels or wind turbines.
This building is an efficient 6 unit apartment design offering generous floor plans for living and entertainment. Multiple, operable windows offer ample natural light and cross ventilation. Open kitchen with eat-in counter compliments today's living.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350
Floor Plan - Main Floor
Full Specs & Features
Depth : 57'
Height : 37' 3"
Basement : 1950 sq/ft
Decks : 120 sq/ft
Main Floor : 1950 sq/ft
Storage : 500 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Garage Ceiling : 8'
Main Ceiling : 9'
Exterior Wall Framing
Exterior Wall Finish : CMU, STUCCO, WOOD SIDING
Framing : ICF
Main Floor Bedrooms
Main Floor Master Bedroom
Additional Room Features
Den Office Study Computer
Great Room Living Room
Grill Deck Sundeck
Energy Efficient Features
What's included in this plan set
See a sample plan set
*See important information before purchasing
All plans are drawn at ¼” scale or larger and include :
Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Ideal for level lot, lower level of home partially or fully underground.
Ideal for level lot, single layer concrete poured directly on grade.
*Options with a fee may take time to prepare. Please call to confirm.
Audio Video Design
Receive an overlay sheet with suggested placement of audio and video components.
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Receive an overlay sheet with suggested placement of lighting fixtures.
Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
