Plan Description

Each of the 3 units in this Modern Deco design building is 2330 sf with 3 bedrooms and 3.5 baths. The building is designed with an ICF exterior wall system providing a minimum R-30 insulation rating. Attached to the exterior wall face is a prefab aluminum panel and a prefab stone covered panel, providing a weather resistant superior insulated wall. All windows are insulated, Low-E units.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Full Specs & Features

Basic Features

Bedrooms : 9
Baths : 9
Stories: 4
Garages: 3


Depth : 47' 3"
Height : 40' 9"
Width : 66' 3"


Total : 8931 sq/ft
Basement : 1500 sq/ft
Decks : 119 sq/ft
Garage : 600 sq/ft
Lower Floor : 2158 sq/ft
Main Floor : 2158 sq/ft
Upper Floor : 2158 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Main Ceiling : 9'


Roof Framing : WD. TRUSS
Roof Type : FLAT TRUSS

Exterior Wall Framing

Exterior Wall Finish : PREFAB METAL & STONE PANEL
Framing : ICF
Insulation : R-30

Bedroom Features

Main Floor Bedrooms
Walk In Closet

Kitchen Features

Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room
Main Floor Laundry

Garage Features

Garage Under
Oversized Garage
Rear Entry Garage

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck


Economical To Build

Energy Efficient Features

Energy Efficient Design

What's included in this plan set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
