The 3 UNIT building is designed as a multi family unit with a central entry. Open decks and expansive windows make for generous living areas. Natural light floods the units from multiple directions offering natural ventilation and open vistas.
The building is shown with exterior treatments of stone masonry and stucco. Exterior walls are designed for “green wall” construction typical with insulated (R30) ICF walls. The flat roof design is suitable for solar panels or wind turbines.
This building is an efficient 6 unit apartment design offering generous floor plans for living and entertainment. Multiple windows offer ample natural light and cross ventilation. Open kitchen with eat-in counter compliments today's living.
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350
Floor Plan - Main Floor
Full Specs & Features
Depth : 53'
Height : 37' 3"
Basement : 500 sq/ft
Decks : 100 sq/ft
Garage : 1800 sq/ft
Main Floor : 2150 sq/ft
